PI3106 Series

Part	Supplied Contents	Outputs and Type	Outputs and Type	Board Type	Power - Output	Regulator Topology	Voltage - Output	Utilized IC / Part	Main Purpose	Voltage - Input [Max]	Voltage - Input [Min]	Contents	Current - Output	Frequency - Switching	Voltage - Isolation	Features	Voltage - Output 1	Operating Temperature [Max]	Operating Temperature [Min]	Type	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Package / Case	Voltage - Input (Min) [Min]	Efficiency	Number of Outputs	Current - Output (Max) [Max]	Voltage - Input (Max) [Max]	Power (Watts)	Applications	Mounting Type	Approval Agency	Standard Number
Vicor Corporation PI3106-01-EVAL1	Board(s)	1 Isolated Output Isolated	1	Fully Populated	50 W	Buck	12 V	PI3106-01	DC/DC Step Down	36 V	18 VDC	Board(s)	4.2 A	900 kHz
Vicor Corporation PI3106-01-HVIZ															2250 VDC	OCP OTP OVP Remote On/Off UVLO	12 V	125 °C	-40 C	Isolated Module	0.26 in	22 mm	6.7 mm	0.87 in	16.5 mm	0.65 "	8-SMD Module	18 V	88.2 %	1	4.2 A	36 V	50 W	ITE (Commercial)	Surface Mount
Vicor Corporation PI3106-00-HVIZ															2250 VDC	Adjustable Output Remote On/Off	12 V	125 °C	-55 C	Isolated Module	0.26 in	22 mm	6.7 mm	0.87 in	16.5 mm	0.65 "	8-SMD Module	16 V	88 %	1	4.17 A	50 V	50 W	ITE (Commercial)	Surface Mount	CSA	60950-1
