Connectors, Interconnects

M80-4S15042F9

Active

HEADERS & WIRE HOUSINGS DATAMATE J-TEK DIL FEMALE VERTICAL SMT CONNECTOR, GOLD CLIP + TIN SHELL, REVERSE FIX WITH 5MM BOARD MOUNT JACKSCREWS, 25+25 CONTACTS

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsComponent Specification (PDF)Datamate Latches and Jackscrews Product Training Module (PDF)+4

Connectors, Interconnects

M80-4S15042F9

Active

Harwin Inc.

HEADERS & WIRE HOUSINGS DATAMATE J-TEK DIL FEMALE VERTICAL SMT CONNECTOR, GOLD CLIP + TIN SHELL, REVERSE FIX WITH 5MM BOARD MOUNT JACKSCREWS, 25+25 CONTACTS

Deep-Dive with AI

DocumentsComponent Specification (PDF)Datamate Latches and Jackscrews Product Training Module (PDF)+4

Specifications Series Pricing Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	M80-4S15042F9

Applications	Automotive, Military, General Purpose
Connector Type	Receptacle
Contact Finish - Mating	Gold
Contact Finish - Post	Tin
Contact Finish Thickness - Mating	12 Áin
Contact Finish Thickness - Mating	0.3 Ám
Contact Finish Thickness - Post	3.5 Ám
Contact Finish Thickness - Post	137.8 Áin
Contact Material	Beryllium Copper
Contact Shape	Circular
Contact Type	Female Socket
Features	Mating Flange, Polarizing Key, Jackscrews, Mounting Flange
Insulation Color	Black
Insulation Height	5.6 mm
Insulation Height	0.22 in
Insulation Material	Polyphenylene Sulfide (PPS), Glass Filled
Mated Stacking Heights	7.8 mm, 8.05 mm
Material Flammability Rating	UL94 V-0
Mounting Type	Surface Mount
Number of Positions	50
Number of Positions Loaded	All
Number of Rows [custom]	2
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-55 C
Pitch - Mating	0.079 "
Pitch - Mating	2 mm
Row Spacing - Mating	2 mm
Row Spacing - Mating	0.079 in
Style	Cable, Board to Board
Termination	Solder
Voltage Rating	800 V

J-Tek Series

...

Part	Note	Contact Termination	Number of Rows [custom]	Operating Temperature [Min]	Operating Temperature [Max]	Color	Pitch [x]	Pitch [x]	Row Spacing	Row Spacing	Insulation Material	Features	Mounting Type	Number of Positions	Contact Type	Connector Type	Mated Stacking Heights [z]	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Row Spacing - Mating	Row Spacing - Mating	Pitch - Mating	Pitch - Mating	Contact Finish - Mating	Number of Positions Loaded	Contact Finish Thickness - Mating [custom]	Contact Finish Thickness - Mating [custom]	Shrouding	Contact Material	Fastening Type	Insulation Height	Insulation Height	Style	Current Rating (Amps)	Contact Length - Post	Contact Length - Post	Termination	Insulation Color	Voltage Rating	Contact Shape	Material Flammability Rating	Contact Finish - Post	Contact Finish Thickness - Post [custom]	Contact Finish Thickness - Post [custom]	Mated Stacking Heights	Applications	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Contact Length - Post [custom]	Contact Length - Post [custom]	Number of Positions [custom]
Harwin Inc. M80-4134098	Contacts Not Included	Crimp	2	-55 C	125 °C	Black	0.079 in	2 mm	2 mm	0.079 in	Polyphenylene Sulfide (PPS) Glass Filled	Mating Flange Polarizing Key	Free Hanging (In-Line)	40	Female Socket	Receptacle
Harwin Inc. M80-5003842			2	-55 C	125 °C						Polyphenylene Sulfide (PPS) Glass Filled	Keying Slot Mating Flange	Through Hole	38	Male Pin	Header	7.3 mm 7.8 mm	12 µin	0.3 µm	2 mm	0.079 in	0.079 "	2 mm	Gold	All	29.5 µin	0.75 µm	Shrouded - 4 Wall	Phosphor Bronze	Threaded	5.6 mm	0.22 in	Board to Board Cable	2.2 A	0.13 "	3.3 mm	Solder	Black	800 VAC	Circular	UL94 V-0	Tin
Harwin Inc. M80-5T15042MC			2	-55 C	121 C						Polyphenylene Sulfide (PPS) Glass Filled	Keying Slot Mating Flange	Through Hole	50	Male Pin	Header				2 mm	0.079 in	0.079 "	2 mm	Gold	All	29.5 µin	0.75 µm	Shrouded - 4 Wall	Phosphor Bronze	Push-Turn Lock	5.6 mm	0.22 in	Board to Board Cable	2.2 A	0.13 "	3.3 mm	Solder	Black	120 VDC	Circular	UL94 V-0	Tin	118.1 µin	3 µm	7.3 mm 7.7 mm 9.75 mm 10.75 mm 13.35 mm 14.75 mm
Harwin Inc. M80-4201405			2	-55 C	125 °C						Polyphenylene Sulfide (PPS) Glass Filled	Jackscrews Mating Flange Mounting Flange Polarizing Key	Through Hole	14	Female Socket	Receptacle		10 Áin	0.25 çm	2 mm	0.079 in	0.079 "	2 mm	Gold	All				Beryllium Copper		5.2 mm	0.205 "	Board to Board Cable		0.118 in	3 mm	Solder	Black	120 VDC	Circular	UL94 V-0	Gold			7.3 mm 7.55 mm	Automotive General Purpose Military	12 Áin	0.3 Ám
Harwin Inc. M80-4170898	Contacts Not Included	Crimp	2	-55 C	125 °C	Black	0.079 in	2 mm	2 mm	0.079 in	Polyphenylene Sulfide (PPS) Glass Filled	Mating Flange Mounting Flange Polarizing Key	Panel Mount	8	Female Socket	Receptacle														Push-Pull
Harwin Inc. M80-4S15042F9			2	-55 C	125 °C						Polyphenylene Sulfide (PPS) Glass Filled	Jackscrews Mating Flange Mounting Flange Polarizing Key	Surface Mount	50	Female Socket	Receptacle		137.8 Áin	3.5 Ám	2 mm	0.079 in	0.079 "	2 mm	Gold	All				Beryllium Copper		5.6 mm	0.22 in	Board to Board Cable				Solder	Black	800 V	Circular	UL94 V-0	Tin			7.8 mm 8.05 mm	Automotive General Purpose Military	12 Áin	0.3 Ám
Harwin Inc. M80-5201242			2	-55 C	125 °C						Polyphenylene Sulfide (PPS) Glass Filled	Keying Slot Mating Flange	Through Hole	12	Male Pin	Header				2 mm	0.079 in	0.079 "	2 mm	Gold	All	29.5 µin	0.75 µm	Shrouded - 4 Wall	Phosphor Bronze	Push-Pull	5.6 mm	0.22 in	Board to Board Cable	2.2 A			Solder	Black	120 VDC	Circular	UL94 V-0	Tin	118.1 µin	3 µm	7.3 mm 7.7 mm 9.75 mm 10.75 mm 13.35 mm 14.75 mm				3.25 mm	0.128 in
Harwin Inc. M80-5423442			2	-55 C	125 °C						Polyphenylene Sulfide (PPS) Glass Filled	Keying Slot Mating Flange Mounting Flange Mounting Hardware	Right Angle Surface Mount		Male Pin	Header				2 mm	0.079 in	0.079 "	2 mm	Gold	All	29.5 µin	0.75 µm	Shrouded - 4 Wall	Copper Alloy	Threaded	5.55 mm	0.218 in	Board to Board Cable	2.2 A			Solder	Black	800 V	Circular	UL94 V-0	Tin									34
Harwin Inc. M80-4205005			2	-55 C	125 °C							Jackscrews Mating Flange Mounting Flange Polarizing Key	Through Hole	50	Female Socket	Receptacle				2 mm	0.079 in	0.079 "	2 mm	Gold	All						5.2 mm	0.205 "	Board to Board Cable		0.118 in	3 mm	Solder	Black	120 VDC		UL94 V-0	Gold			7.3 mm 7.55 mm		12 Áin	0.3 Ám
Harwin Inc. M80-5434242			2	-55 C	125 °C						Polyphenylene Sulfide (PPS) Glass Filled	Keying Slot Mating Flange Mounting Flange Mounting Hardware	Right Angle Surface Mount	42	Male Pin	Header				2 mm	0.079 in	0.079 "	2 mm	Gold	All	29.5 µin	0.75 µm	Shrouded - 4 Wall	Copper Alloy	Threaded	5.55 mm	0.218 in	Board to Board Cable	2.2 A			Solder	Black	800 V	Circular	UL94 V-0	Tin
