Capacitors

C328C432F3G5TA7301

Active

KEMET

MULTILAYER CERAMIC CAPACITORS MLCC - LEADED 25V 4300PF C0G 1% LS=5.08MM

Deep-Dive with AI

DocumentsDatasheet

Specifications Series Pricing Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	C328C432F3G5TA7301

Applications	General Purpose
Capacitance	4300 pF
Features	Low ESL
Height - Seated (Max)	7.62 mm
Height - Seated (Max) [Max]	0.3 in
Lead Spacing	0.2 in
Lead Spacing	5.08 mm
Lead Style	Formed Leads
Mounting Type	Through Hole
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-55 C
Package / Case	Radial
Size / Dimension [x]	0.2 in
Size / Dimension [x]	5.08 mm
Size / Dimension [y]	3.18 mm
Size / Dimension [y]	0.125 "
Temperature Coefficient	NP0, C0G
Tolerance	1 %
Voltage - Rated	25 VDC

C328C Series

...

Part	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Height - Seated (Max) [Max]	Height - Seated (Max)	Tolerance	Capacitance	Temperature Coefficient	Lead Spacing	Lead Spacing	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type	Voltage - Rated	Features	Package / Case	Applications	Lead Style
KEMET C328C123F1G5TA	3.18 mm	0.2 in	5.08 mm	0.125 "	0.3 in	7.62 mm	1 %	0.012 µF	C0G NP0	0.2 in	5.08 mm	-55 C	125 °C	Through Hole	100 V	Low ESL	Radial	General Purpose	Formed Leads
KEMET C328C432F3G5TA7301	3.18 mm	0.2 in	5.08 mm	0.125 "	0.3 in	7.62 mm	1 %	4300 pF	C0G NP0	0.2 in	5.08 mm	-55 C	125 °C	Through Hole	25 VDC	Low ESL	Radial	General Purpose	Formed Leads
KEMET C328C220JAG5TA	3.18 mm	0.2 in	5.08 mm	0.125 "	0.3 in	7.62 mm	5 %	22 pF	C0G NP0	0.2 in	5.08 mm	-55 C	125 °C	Through Hole	250 V	Low ESL	Radial	General Purpose	Formed Leads
KEMET C328C821F3G5TA7301	3.18 mm	0.2 in	5.08 mm	0.125 "	0.3 in	7.62 mm	1 %	820 pF	C0G NP0	0.2 in	5.08 mm	-55 C	125 °C	Through Hole	25 VDC	Low ESL	Radial	General Purpose	Formed Leads
KEMET C328C360J3G5TA	3.18 mm	0.2 in	5.08 mm	0.125 "	0.3 in	7.62 mm	5 %	36 pF	C0G NP0	0.2 in	5.08 mm	-55 C	125 °C	Through Hole	25 VDC	Low ESL	Radial	General Purpose	Formed Leads
KEMET C328C301FAG5TA	3.18 mm	0.2 in	5.08 mm	0.125 "	0.3 in	7.62 mm	1 %	300 pF	C0G NP0	0.2 in	5.08 mm	-55 C	125 °C	Through Hole	250 V	Low ESL	Radial	General Purpose	Formed Leads
KEMET C328C393G5G5TA7301	3.18 mm	0.2 in	5.08 mm	0.125 "	0.3 in	7.62 mm	2 %	0.039 µF	C0G NP0	0.2 in	5.08 mm	-55 C	125 °C	Through Hole	50 VDC	Low ESL	Radial	General Purpose	Formed Leads
KEMET C328C122GAG5TA7301	3.18 mm	0.2 in	5.08 mm	0.125 "	0.3 in	7.62 mm	2 %	1200 pF	C0G NP0	0.2 in	5.08 mm	-55 C	125 °C	Through Hole	250 V	Low ESL	Radial	General Purpose	Formed Leads
KEMET C328C131F3G5TA	3.18 mm	0.2 in	5.08 mm	0.125 "	0.3 in	7.62 mm	1 %	130 pF	C0G NP0	0.2 in	5.08 mm	-55 C	125 °C	Through Hole	25 VDC	Low ESL	Radial	General Purpose	Formed Leads
KEMET C328C272GAG5TA	3.18 mm	0.2 in	5.08 mm	0.125 "	0.3 in	7.62 mm	2 %	2700 pF	C0G NP0	0.2 in	5.08 mm	-55 C	125 °C	Through Hole	250 V	Low ESL	Radial	General Purpose	Formed Leads

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	N/A	0	$ 0.42
	Tape & Reel (TR)	2500	$ 0.38
Mouser	N/A	1	$ 3.48
		10	$ 2.51
		50	$ 2.17
		100	$ 1.91
		500	$ 1.71
		1000	$ 1.55
		2500	$ 1.21

Description

General part information

C328C Series

4300 pF ±1% 25V Ceramic Capacitor C0G, NP0 Radial
