Industrial Automation and Controls

6ES76470BA000YA2

Active

SIMATIC IOT2050

Search across all available documentation for this part.

Industrial Automation and Controls

Active

SIMATIC IOT2050

Technical Specifications

Parameters and characteristics for this part

Specification	6ES76470BA000YA2

Approval Agency	CE, FCC, UL, cULus, KC, EAC, RCM
For Use With/Related Products	SIMATIC IOT2050
Ingress Protection	IP20
Mounting Type	DIN Rail
Number of Outputs and Type	Digital
Number of Outputs and Type	20
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	-20 ░C
Termination Style	RJ45
Type	Input, Output (I/O) Module
Voltage - Supply	12 VDC, 24 V

Part	Operating Temperature [Min]	Operating Temperature [Max]	Ingress Protection	Approval Agency	Termination Style	Mounting Type	For Use With/Related Products	Voltage - Supply	Type	Memory	Memory	Display Type	Operating System	Core Processor	Core Processor	Storage	Storage	Voltage - Supply [Min]	Voltage - Supply [Max]	Number of Outputs and Type	Number of Outputs and Type
Siemens 6ES76470BA001YA2	-20 ░C	70 °C	IP20	CE cULus EAC FCC KC RCM UL	RJ45	DIN Rail	SIMATIC IOT2050	12 VDC 24 V	Interface Module
Siemens 6ES76470BB001YA2
Siemens 6ES76470JB000YA2	0 °C	45 °C	IP20	CE CSA cULus EAC KC RCM UL		DIN Rail Wall Mount		24 V	Box PC	LPDDR4	8 GB	No Display	Without Operating System	1.5 GHz	NVIDIA Carmel ARM® Cortex™-V8.2	16 GB	eMMC
Siemens 6ES76470BA200SP2					Screw Terminal	DIN Rail	SIMATIC IOT2050		Input Output (I/O) Module
Siemens 6ES76470AA001YA2	0 °C	50 °C	IP20	CE cULus KC UL	Screw Terminal	DIN Rail	SIMATIC IoT2040		Interface Module									9 V	36 V
Siemens 6ES76470BA000YA2	-20 ░C	70 °C	IP20	CE cULus EAC FCC KC RCM UL	RJ45	DIN Rail	SIMATIC IOT2050	12 VDC 24 V	Input Output (I/O) Module											Digital	20

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Input, Output (I/O) Module DIN Rail 12VDC, 24VDC
