Specification	1815P 0101000

Cable Type	Multi-Pair
Conductor Insulation	Fluorinated Ethylene-Propylene (FEP)
Conductor Material	Copper, Tinned
Conductor Strand [custom]	30 AWG
Conductor Strand [custom]	7
Features	Drain Wire
Jacket (Insulation) Diameter [diameter]	0.317 in
Jacket (Insulation) Diameter [diameter]	8.05 mm
Jacket (Insulation) Material	Polyvinylidene Fluoride (PVDF)
Jacket (Insulation) Thickness [x]	0.381 mm
Jacket (Insulation) Thickness [x]	0.015 in
Jacket Color	Black
Length	304.8 m
Length	1000 ft
Number of Conductors	8
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-40 C
Ratings	UL Style CMP
Shield Coverage	100 %
Shield Material	Aluminum, Polyester
Shield Type	Foil
Usage	Audio
Voltage	300 VDC
Wire Gauge	22 AWG

1815P Series

Part	Shield Coverage	Shield Material	Jacket (Insulation) Thickness [x]	Jacket (Insulation) Thickness [x]	Jacket Color	Cable Type	Number of Conductors	Features	Operating Temperature [Min]	Operating Temperature [Max]	Length	Length	Conductor Strand [custom]	Conductor Strand [custom]	Ratings	Jacket (Insulation) Material	Shield Type	Conductor Insulation	Wire Gauge	Conductor Material	Usage	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Voltage
Belden Inc. 1815P 0101000	100 %	Aluminum Polyester	0.381 mm	0.015 in	Black	Multi-Pair	8	Drain Wire	-40 C	105 ░C	304.8 m	1000 ft	30 AWG	7	UL Style CMP	Polyvinylidene Fluoride (PVDF)	Foil	Fluorinated Ethylene-Propylene (FEP)	22 AWG	Copper Tinned	Audio	0.317 in	8.05 mm	300 VDC

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	N/A	0	$ 0.00

General part information

8 (4 Pair) Conductor Multi-Pair Cable Black 22 AWG Foil 1000.0' (304.8m)
