Vigortronix is a UK-based manufacturer of transformers, power supplies, inductors, and wound magnetic components with in-house design capabilities and over 75 years of combined industry experience.
Parts that are not part of a series
Company background and product focus
Vigortronix is a leading manufacturer of transformers, power supplies, and wound magnetics with an international reputation for quality. Founded in 2007 and based in the UK, the company brings over 75 years of combined industry experience to the design, manufacture, and distribution of electronic components.
With an in-house design department and on-site manufacturing facility, Vigortronix can respond quickly to customer requirements. Their 5,500 sq. ft. warehouse along with offshore facilities ensures comprehensive stock of standard transformers, wound components, and power supplies available for immediate delivery.
© 2026 Zenode. All rights reserved.
Product families from Vigortronix
| Series | Category | Parts | Status | Description |
|---|---|---|---|---|
No series available
This manufacturer doesn't have any product series listed yet. Check back later or contact us if you're looking for specific parts.
Parts from Vigortronix that are not part of a series
| Part Information | Pricing (lowest) | Size / Dimension Length | Size / Dimension Width | Power Level | Impedance - Primary (Ohms) | Impedance - Secondary (Ohms) Qualifier | Impedance - Secondary (Ohms) | Mounting Type | DC Resistance (DCR) - Primary | Frequency Range (Max) | Frequency Range (Min) | Termination Style | DC Resistance (DCR) - Secondary | Turns Ratio - Secondary | Turns Ratio - Primary | Transformer Type | Height - Seated (Max) | Operating Temperature (Max) | Operating Temperature (Min) | Voltage - Isolation | Frequency Response (Max) | Frequency Response (Min) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Vigortronix AUDIO XFMR 800OHM 1:1 2MW | Sign in to see pricing | 0.807 in | 0.63 in | 2 mW | 800 Ohms | CT | 800 Ohms | Through Hole | 63 Ohm | 15 kHz | 200 Hz | PC Pin | 84 Ohm | 1 | 1 | Impedance Matching | 0.669 in | — | — | — | — | — |
 Vigortronix AUDIO XFMR 600:6OHM BIFILAR | Sign in to see pricing | 1.697 in | 1.406 in | — | 600 Ohms | — | 6 Ohms | Through Hole | 15.34 Ohm | 20 kHz | 20 Hz | PC Pin | 44 mOhm | — | — | Impedance Matching | 1.181 in | 70 °C | -20 °C | — | — | — |
 Vigortronix AUDIO TRANSFORMER, 150 OHM, 3.75 OHM, THROUGH HOLE ROHS COMPLIANT: YES | Sign in to see pricing | 1.083 in | 0.906 in | — | 150 Ohms | — | 3.75 Ohms | Through Hole | 10 Ohm | 30 kHz | 30 Hz | PC Pin | 360 mOhm | — | — | Impedance Matching | 0.886 in | — | — | 1000 Vrms | — | — |
 Vigortronix AUDIO TRANSFORMER, 150 OHM, 600 OHM, THROUGH HOLE ROHS COMPLIANT: YES | Sign in to see pricing | 1.083 in | 0.906 in | — | 150 Ohms | — | 600 Ohms | Through Hole | 10 Ohm | 35 kHz | 30 Hz | PC Pin | 55 Ohm | — | — | Impedance Matching | 0.886 in | — | — | 1000 Vrms | — | — |
 Vigortronix AUDIO TRANSFORMER, 150 OHM, 6.25 OHM, THROUGH HOLE ROHS COMPLIANT: YES | Sign in to see pricing | 1.083 in | 0.906 in | — | 150 Ohms | — | 3.25 kOhm | Through Hole | 9.6 Ohm | 25 kHz | 30 Hz | PC Pin | 535 Ohm | — | — | Impedance Matching | 0.886 in | — | — | 1000 Vrms | — | — |
 Vigortronix AUDIO TRANSFORMER, 150 OHM, 150 OHM, THROUGH HOLE ROHS COMPLIANT: YES | Sign in to see pricing | 1.083 in | 0.906 in | — | 150 Ohms | — | 150 Ohms | Through Hole | 15 Ohm | 30 kHz | 30 Hz | PC Pin | 20 Ohm | — | — | Impedance Matching | 0.886 in | — | — | 1000 Vrms | — | — |
 Vigortronix AUDIO TRANSFORMER, 600 OHM, 600 OHM, THROUGH HOLE ROHS COMPLIANT: YES | Sign in to see pricing | 1.083 in | 0.906 in | — | 600 Ohms | — | 600 Ohms | Through Hole | 42 Ohm | 35 kHz | 30 Hz | PC Pin | 58 Ohm | — | — | Impedance Matching | 0.886 in | — | — | 1000 Vrms | — | — |
 Vigortronix AUDIO XFMR ENCAP MATCH | Sign in to see pricing | 0.709 in | 0.709 in | — | 600 Ohms | — | 2.4 kOhm | Through Hole | 145 Ohm | — | — | PC Pin | 350 Ohm | 2 | 1 | Line (Audio Power Distribution) | 12.7 mm | — | — | 1500 Vrns | 0.2 dB | -2 dB |
 Vigortronix AUDIO TRANSFORMER, 1:1CT, 600 OHM, 600 OHM, 25 KHZ, 1 KV | Sign in to see pricing | 0.709 in | 0.709 in | — | 600 Ohms | CT | 600 Ohms | Through Hole | 109 Ohm | 25 kHz | 60 Hz | PC Pin | 65 Ohm | 1 | 1 | Miniature Epoxy Potted | 12.7 mm | — | — | 1500 Vrns | — | — |
Vigortronix AUDIO XFMR ENCAP MATCH | Sign in to see pricing | 0.709 in | 0.709 in | — | 800 Ohms | CT | 800 Ohms | Through Hole | 105 Ohm | 25 kHz | 60 Hz | PC Pin | 134 Ohm | 1 | 1 | Miniature Epoxy Potted | 12.7 mm | — | — | 1500 Vrns | — | — |
