Product families from Trustcap
| Series | Category | Parts | Status | Description |
|---|---|---|---|---|
Parts that are not part of a series
© Zenode. All rights reserved.
No series available
This manufacturer doesn't have any product series listed yet. Check back later or contact us if you're looking for specific parts.
Parts from Trustcap that are not part of a series
| Part Information | Pricing (lowest) | Lifetime | Capacitance | Size / Dimension Diameter | Applications | Ripple Current | ESR (Equivalent Series Resistance) | Package / Case | Tolerance | Operating Temperature (Min) | Operating Temperature (Max) | Mounting Type | Height - Seated (Max) | Voltage - Rated | Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Trustcap 30W AUXILIARY MODULE (DUAL OUTPU | Sign in to see pricing | — | — | — | — | — | — | — | — | — | — | — | — | — | — |
 Trustcap CAP ALUM POLY 220UF 20% 6.3V SMD | Sign in to see pricing | 2000 Hrs | 220 µF | 0.248 in | General Purpose | 2 A | 25 mOhm | FlatPack, Tabbed | 20 % | -55 °C | 105 °C | Surface Mount | 0.118 in | 6.3 V | Polymer |
 Trustcap CAP ALUM POLY 330UF 20% 6.3V SMD | Sign in to see pricing | 2000 Hrs | 330 µF | 0.248 in | General Purpose | 2.4 A | 20 mOhm | FlatPack, Tabbed | 20 % | -55 °C | 105 °C | Surface Mount | 0.157 in | 6.3 V | Polymer |
Trustcap CAP ALUM POLY 150UF 20% 16V SMD | Sign in to see pricing | 2000 Hrs | 150 µF | 0.248 in | General Purpose | 1.4 A | 35 mOhm | FlatPack, Tabbed | 20 % | -55 °C | 105 °C | Surface Mount | 0.118 in | 16 V | Polymer |
Trustcap CAP ALUM POLY 180UF 20% 16V SMD | Sign in to see pricing | 2000 Hrs | 180 µF | 0.248 in | General Purpose | 1.9 A | 32 mOhm | FlatPack, Tabbed | 20 % | -55 °C | 105 °C | Surface Mount | 0.157 in | 16 V | Polymer |
Trustcap CAP ALUM POLY 68UF 20% 16V SMD | Sign in to see pricing | 2000 Hrs | 68 µF | 0.197 in | General Purpose | — | — | FlatPack, Tabbed | 20 % | -55 °C | 105 °C | Surface Mount | 0.118 in | 16 V | Polymer |
Trustcap CAP ALUM POLY 100UF 20% 25V SMD | Sign in to see pricing | 2000 Hrs | 100 µF | 0.248 in | General Purpose | 1.1 A | 50 mOhm | FlatPack, Tabbed | 20 % | -55 °C | 105 °C | Surface Mount | 0.118 in, 0.126 in | 25 VAC | Polymer |
Trustcap CAP ALUM POLY 100UF 20% 25V SMD | Sign in to see pricing | 2000 Hrs | 100 µF | 0.248 in | General Purpose | 1.9 A | 40 mOhm | FlatPack, Tabbed | 20 % | -55 °C | 105 °C | Surface Mount | 0.157 in | 25 VAC | Polymer |
Trustcap CAP ALUM POLY 47UF 20% 25V SMD | Sign in to see pricing | 2000 Hrs | 47 µF | 0.197 in | General Purpose | — | — | FlatPack, Tabbed | 20 % | -55 °C | 105 °C | Surface Mount | 0.118 in | 25 VAC | Polymer |
Trustcap CAP ALUM POLY 180UF 20% 12V SMD | Sign in to see pricing | 2000 Hrs | 180 µF | 0.248 in | General Purpose | 1.6 A | 35 mOhm | FlatPack, Tabbed | 20 % | -55 °C | 105 °C | Surface Mount | 0.118 in | 12 VAC | Polymer |
