Product families from Trafag Sensors and Controls
| Series | Category | Parts | Status | Description |
|---|---|---|---|---|
No series available
This manufacturer doesn't have any product series listed yet. Check back later or contact us if you're looking for specific parts.
Parts from Trafag Sensors and Controls that are not part of a series
| Part Information | Pricing (lowest) | Port Style | Operating Temperature (Max) | Operating Temperature (Min) | Output Current (Max) | Output Current (Min) | Operating Pressure (Min) | Operating Pressure (Max) | Port Diameter | Port Gender | Port Feature | Voltage - Supply (Minimum) | Voltage - Supply (Maximum) | Output Type | Maximum Pressure | Termination Style | Pressure Type | Package / Case | Accuracy | Pin Count | Operating Pressure | Output Voltage (Max) | Output Voltage (Min) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Trafag Sensors and Controls HYDROGEN PRESSURE TRANSMITTER | Sign in to see pricing | Threaded | 125 °C | -40 °C | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — |
 Trafag Sensors and Controls HYDROGEN PRESSURE TRANSMITTER | Sign in to see pricing | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — |
 Trafag Sensors and Controls SENSOR 60PSIG 1/4"NPT .02A | Sign in to see pricing | Threaded | 125 °C | -40 °C | 20 mA | 4 mA | -14.5 PSI | 60 PSI | 0.25 " | Male | NPT | 9 VDC | 32 V | Analog Current | 300 PSI | DIN43650-C | Gauge | Cylinder, Threaded | 0.5 % RH | — | — | — | — |
Trafag Sensors and Controls SENSOR 100PSIG 1/4"NPT .02A | Sign in to see pricing | Threaded | 125 °C | -40 °C | 20 mA | 4 mA | -14.5 PSI | 100 PSI | 0.25 " | Male | NPT | 9 VDC | 32 V | Analog Current | 450 PSI | DIN43650-C | Gauge | Cylinder, Threaded | 0.5 % RH | — | — | — | — |
 Trafag Sensors and Controls SENSOR 150PSIG 1/4"NPT .02A | Sign in to see pricing | Threaded | 125 °C | -40 °C | 20 mA | 4 mA | -14.5 PSI | 150 PSI | 0.25 " | Male | NPT | 9 VDC | 32 V | Analog Current | 600 PSI | DIN43650-C | Gauge | Cylinder, Threaded | 0.5 % RH | — | — | — | — |
 Trafag Sensors and Controls SENSOR 200PSIG 1/4"NPT .02A | Sign in to see pricing | Threaded | 125 °C | -40 °C | 20 mA | 4 mA | — | — | 0.25 " | Male | NPT | 9 VDC | 32 V | Analog Current | — | M12x1 | Gauge | Cylinder, Threaded | 0.5 % RH | 4 | 200 PSI | — | — |
 Trafag Sensors and Controls SENSOR 10000PSIG 7/16" 5V | Sign in to see pricing | Threaded | 125 °C | -40 °C | — | — | — | — | 0.4375 in | Male | SAE4, UNF | 9 VDC | 32 V | Analog Current | 18750 PSI | M12x1 | Gauge | Cylinder, Threaded | 0.5 % RH | 4 | 10000 PSI | 5 V | 0 V |
Trafag Sensors and Controls SENSOR 3000PSIG 1/4"NPT 10V | Sign in to see pricing | Threaded | 125 °C | -40 °C | — | — | — | — | 0.25 " | Male | NPT | 15 VDC | 32 V | Analog Voltage | 9000 PSI | DIN43650-C | Gauge | Cylinder, Threaded | 0.5 % RH | — | 3000 PSI | 10 V | 0 V |
Trafag Sensors and Controls SENSOR 3000PSIG 1/4"NPT .02A | Sign in to see pricing | Threaded | 125 °C | -40 °C | 20 mA | 4 mA | — | — | 0.25 " | Male | NPT | 9 VDC | 32 V | Analog Current | 9000 PSI | DIN43650-C | Gauge | Cylinder, Threaded | 0.5 % RH | — | 3000 PSI | — | — |
Trafag Sensors and Controls SENSOR 3000PSIG 1/4"NPT 4.5V | Sign in to see pricing | Threaded | 125 °C | -40 °C | — | — | — | — | 0.25 " | Male | NPT | 4.75 V | 5.25 V | Analog Voltage | 9000 PSI | DIN43650-C | Gauge | Cylinder, Threaded | 0.5 % RH | — | 3000 PSI | 4.5 V | 0.5 V |
