Product families from Suscon
| Series | Category | Parts | Status | Description |
|---|---|---|---|---|
Parts that are not part of a series
© Zenode. All rights reserved.
No series available
This manufacturer doesn't have any product series listed yet. Check back later or contact us if you're looking for specific parts.
Parts from Suscon that are not part of a series
| Part Information | Pricing (lowest) | Operating Temperature (Min) | Operating Temperature (Max) | Ripple Current | Capacitance | Voltage - Rated | Size / Dimension Diameter | Mounting Type | Lifetime | Applications | Lead Spacing | Polarization | Height - Seated (Max) | Tolerance | Package / Case | Ratings | Impedance | Surface Mount Land Width | Surface Mount Land Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Suscon CAP ALUM 6800UF 20% 50V SNAP TH | Sign in to see pricing | -40 °C | 105 °C | 3.2 A, 4.8 A | 6800 µF | 50 V | 1.181 in | Through Hole | 2000 Hrs | General Purpose | 0.394 in | Polar | 1.969 in | 20 % | Can - Snap-In, Radial | — | — | — | — |
 Suscon CAP ALUM 100UF 20% 6.3V SMD | Sign in to see pricing | -55 °C | 105 °C | 56 mA, 140 mA | 100 µF | 6.3 V | 0.248 in | Surface Mount | 1000 Hrs | Automotive | — | Polar | 0.213 in | 20 % | Can - SMD, Radial | AEC-Q200 | 1 Ohms | 0.26 in | 0.26 in |
 Suscon CAP ALUM 22UF 20% 6.3V SMD | Sign in to see pricing | -55 °C | 105 °C | 31.5 mA, 90 mA | 22 µF | 6.3 V | 0.157 in | Surface Mount | 2000 Hrs | Automotive | — | Polar | 0.236 in | 20 % | Can - SMD, Radial | AEC-Q200 | 1.35 Ohms | 0.169 in | 0.169 in |
Suscon CAP ALUM 100UF 20% 10V SMD | Sign in to see pricing | -55 °C | 105 °C | 92 mA, 230 mA | 100 µF | 10 V | 0.248 in | Surface Mount | 2000 Hrs | Automotive | — | Polar | 0.236 in | 20 % | Can - SMD, Radial | AEC-Q200 | 400 mOhms | 0.26 in | 0.26 in |
Suscon CAP ALUM 22UF 20% 10V SMD | Sign in to see pricing | -55 °C | 105 °C | 28 mA, 80 mA | 22 µF | 10 V | 0.157 in | Surface Mount | 2000 Hrs | Automotive | — | Polar | 0.236 in | 20 % | Can - SMD, Radial | AEC-Q200 | 18 Ohms | 0.169 in | 0.169 in |
 Suscon CAP ALUM 330UF 20% 10V SMD | Sign in to see pricing | -55 °C | 105 °C | 270 mA, 450 mA | 330 µF | 10 V | 0.315 in | Surface Mount | 5000 Hrs | Automotive | — | Polar | 0.394 in | 20 % | Can - SMD, Radial | AEC-Q200 | 170 mOhm | 0.327 in | 0.327 in |
Suscon CAP ALUM 10UF 20% 16V SMD | Sign in to see pricing | -55 °C | 105 °C | 10.5 mA, 30 mA | 10 µF | 16 V | 0.157 in | Surface Mount | 1000 Hrs | Automotive | — | Polar | 0.213 in | 20 % | Can - SMD, Radial | AEC-Q200 | 3 Ohms | 0.169 in | 0.169 in |
Suscon CAP ALUM 22UF 20% 16V SMD | Sign in to see pricing | -55 °C | 105 °C | 31.5 mA, 90 mA | 22 µF | 16 V | 0.157 in | Surface Mount | 2000 Hrs | Automotive | — | Polar | 0.236 in | 20 % | Can - SMD, Radial | AEC-Q200 | 1.35 Ohms | 0.169 in | 0.169 in |
Suscon CAP ALUM 220UF 20% 16V SMD | Sign in to see pricing | -55 °C | 105 °C | 168 mA, 280 mA | 220 µF | 16 V | 0.248 in | Surface Mount | 2000 Hrs | Automotive | — | Polar | 0.303 in | 20 % | Can - SMD, Radial | AEC-Q200 | 0.34 Ohms | 0.26 in | 0.26 in |
 Suscon CAP ALUM 680UF 20% 16V SMD | Sign in to see pricing | -55 °C | 105 °C | 510 mA, 850 mA | 680 µF | 16 V | 0.394 in | Surface Mount | 2000 Hrs | Automotive | — | Polar | 0.394 in | 20 % | Can - SMD, Radial | AEC-Q200 | 80 mOhms | 0.406 in | 0.406 in |
