Product families from Schaltbau
| Series | Category | Parts | Status | Description |
|---|---|---|---|---|
Parts that are not part of a series
© Zenode. All rights reserved.
No series available
This manufacturer doesn't have any product series listed yet. Check back later or contact us if you're looking for specific parts.
Parts from Schaltbau that are not part of a series
| Part Information | Pricing (lowest) | Mounting Type | Color | Fastening Type | Ingress Protection IP Rating | Ingress Protection Description | Operating Temperature (Min) | Operating Temperature (Max) | Orientation Angle | Contact Finish - Mating | Current Rating | Voltage Rating | Primary Material | Grade | Termination | Shell Material | Number of Positions | Mounting Feature | Termination Style | Actuator Type | Voltage Rating - DC | Voltage Rating - AC | Ingress Protection | Operating Force | Circuit | Mechanical Life (Cycles) | Release Force | Quick Connect Size (0.250") | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Schaltbau VG95351 C7 | Sign in to see pricing | Panel Mount, Through Hole | Black | Bayonet Lock | IP68 | Dust Tight, Waterproof | -57 °C | 85 °C | 0 ° | Gold | 2.5 A | 50 V | Metal | Military | Solder Cup | Stainless Steel | 7 | Flange | — | — | — | — | — | — | — | — | — | — | — |
 Schaltbau S800 A | Sign in to see pricing | Chassis, Panel Mount | — | — | — | — | -40 °C | 85 °C | — | — | 10 A | — | — | — | — | — | — | — | Screw Terminal | Lever, Roller | 400 V | 400 Vpk | IP40 | 234 gf | SPDT-DB | 10000000 Cycles | 20 gf | — | — |
Schaltbau S800 A 20 | Sign in to see pricing | Chassis, Panel Mount | — | — | — | — | -40 °C | 85 °C | — | — | 10 A | — | — | — | — | — | — | — | Quick Connect | Lever, Roller | 400 V | 400 Vpk | IP40 | 234 gf | SPDT-DB | 10000000 Cycles | 20 gf | 0.25 in | — |
Schaltbau S800 B | Sign in to see pricing | Chassis, Panel Mount | — | — | — | — | -40 °C | 85 °C | — | — | 10 A | — | — | — | — | — | — | — | Screw Terminal | Round (Pin Plunger) | 400 V | 400 Vpk | IP40 | 336 gf | SPDT-DB | 10000000 Cycles | 20 gf | — | — |
Schaltbau S800 E | Sign in to see pricing | Chassis, Panel Mount | — | — | — | — | -40 °C | 85 °C | — | — | 10 A | — | — | — | — | — | — | — | Screw Terminal | Lever, Roller | 400 V | 400 Vpk | IP40 | 234 gf | SPDT-DB | 10000000 Cycles | 20 gf | — | — |
Schaltbau S800 E 20 | Sign in to see pricing | Chassis, Panel Mount | — | — | — | — | -40 °C | 85 °C | — | — | 10 A | — | — | — | — | — | — | — | Quick Connect | Lever, Roller | 400 V | 400 Vpk | IP40 | 234 gf | SPDT-DB | 10000000 Cycles | 20 gf | 0.25 in | — |
Schaltbau S800 E 40 | Sign in to see pricing | Chassis Mount | — | — | — | — | -40 °C | 85 °C | — | — | 10 A | — | — | — | — | — | — | — | Screw Terminal | Lever, Roller | 400 V | 400 Vpk | IP40 | 397 gf | SPDT-DB | 10000000 Cycles | 810 gf | — | — |
Schaltbau S800 AS | Sign in to see pricing | Chassis, Panel Mount | — | — | — | — | -40 °C | 85 °C | — | — | 10 A | — | — | — | — | — | — | — | Screw Terminal | Lever, Roller | 400 V | 400 Vpk | IP40 | 234 gf | SPDT-DB | 10000000 Cycles | 20 gf | — | — |
 Schaltbau S820 B 7 | Sign in to see pricing | Chassis Mount | — | — | — | — | -40 °C | 85 °C | — | — | 20 A | — | — | — | — | — | — | — | Screw Terminal | Round (Pin Plunger) | 400 V | 400 Vpk | IP40 | 815 gf | SPDT-DB | 1000000 Cycles | 153 gf | — | — |
Schaltbau S820 A 7/40 L | Sign in to see pricing | Chassis, Panel Mount | — | — | — | — | -40 °C | 85 °C | — | — | 20 A | — | — | — | — | — | — | — | Screw Terminal | Lever, Roller | 400 V | 400 Vpk | IP40 | 611 gf | SPDT-DB | 1000000 Cycles | 910 gf | — | Magnetic Blowout |
