Product families from RFE/Fuzetec
| Series | Category | Parts | Status | Description |
|---|---|---|---|---|
Parts that are not part of a series
© Zenode. All rights reserved.
No series available
This manufacturer doesn't have any product series listed yet. Check back later or contact us if you're looking for specific parts.
Parts from RFE/Fuzetec that are not part of a series
| Part Information | Pricing (lowest) | Approval Agency | Package / Case | Current - Trip (It) | Voltage - Max | Time to Trip | Current - Max | Operating Temperature (Min) | Operating Temperature (Max) | Current - Hold (Ih) (Max) | Resistance - Post Trip (R1) (Max) | Lead Spacing | Mounting Type | Resistance - Initial (Ri) (Min) | Height - Seated (Max) | Size / Dimension Length | Size / Dimension Width |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 RFE/Fuzetec RESETTABLE FUSE - PPTC RADIAL LE | Sign in to see pricing | cUL, TUV, UL | Disc, Radial | 17 A | 16 V | 12.5 s | 100 A | -40 °C | 85 °C | 10 A | 12 mOhms | 0.201 in | Through Hole | 3 mOhms | 0.949 in | 0.65 in | 0.118 in |
 RFE/Fuzetec RESETTABLE FUSE - PPTC RADIAL LE | Sign in to see pricing | — | Disc, Radial | 18.7 A | 16 V | 13.5 s | 100 A | -40 °C | 85 °C | 11 A | 10 mOhms | 0.201 in | Through Hole | 3 mOhms | 1.024 in | 0.689 in | 0.118 in |
RFE/Fuzetec RESETTABLE FUSE - PPTC RADIAL LE | Sign in to see pricing | — | Disc, Radial | 20.4 A | 16 V | 16 s | 100 A | -40 °C | 85 °C | 12 A | 9 mOhms | 0.402 in | Through Hole | 2 mOhms | 1.102 in | 0.689 in | 0.142 in |
RFE/Fuzetec RESETTABLE FUSE - PPTC RADIAL LE | Sign in to see pricing | — | Disc, Radial | 23.8 A | 16 V | 20 s | 100 A | -40 °C | 85 °C | 14 A | 8 mOhms | 0.402 in | Through Hole | 2 mOhms | 1.098 in | 1.098 in | 0.142 in |
RFE/Fuzetec RESETTABLE FUSE - PPTC RADIAL LE | Sign in to see pricing | cUL, TUV, UL | Disc, Radial | 4.7 A | 16 V | 5 s | 100 A | -40 °C | 85 °C | 2.5 A | 53 mOhms | 0.201 in | Through Hole | 22 mOhms | 0.504 in | 0.35 in | 0.118 in |
RFE/Fuzetec RESETTABLE FUSE - PPTC RADIAL LE | Sign in to see pricing | — | Disc, Radial | 5.1 A | 16 V | 2 s | 100 A | -40 °C | 85 °C | 3 A | 105 mOhms | 0.201 in | Through Hole | 34 mOhms | 0.433 in | 0.28 in | 0.118 in |
RFE/Fuzetec RESETTABLE FUSE - PPTC RADIAL LE | Sign in to see pricing | cUL, TUV, UL | Disc, Radial | 6.8 A | 16 V | 3.5 s | 100 A | -40 °C | 85 °C | 4 A | 63 mOhms | 0.201 in | Through Hole | 20 mOhms | 0.504 in | 0.35 in | 0.118 in |
RFE/Fuzetec RESETTABLE FUSE - PPTC RADIAL LE | Sign in to see pricing | — | Disc, Radial | 8.5 A | 16 V | 3.6 s | 100 A | -40 °C | 85 °C | 5 A | 44 mOhms | 0.201 in | Through Hole | 14 mOhms | 0.563 in | 0.409 in | 0.118 in |
RFE/Fuzetec RESETTABLE FUSE - PPTC RADIAL LE | Sign in to see pricing | cUL, TUV, UL | Disc, Radial | 10.2 A | 16 V | 5.8 s | 100 A | -40 °C | 85 °C | 6 A | 0.033 Ohms | 0.201 in | Through Hole | 9 mOhms | 0.673 in | 0.421 in | 0.118 in |
RFE/Fuzetec RESETTABLE FUSE - PPTC RADIAL LE | Sign in to see pricing | — | Disc, Radial | 11.9 A | 16 V | 8 s | 100 A | -40 °C | 85 °C | 7 A | 21 mOhms | 0.201 in | Through Hole | 6 mOhms | 0.776 in | 0.441 in | 0.118 in |
