PTR Hartmann GmbH is a German manufacturer of high-quality PCB terminal blocks, test probes, contact pins, and inductive components, serving the electronics and automotive industries since 1979.
Parts that are not part of a series
Company background and product focus
PTR Hartmann GmbH is an internationally active German manufacturer headquartered in Werne, Germany. Since 1979, PTR has been developing terminals of the highest quality and continuously expanding its portfolio with innovative electromechanical components for the global market.
PTR Hartmann manufactures a comprehensive range of connection technology products:
As part of the Phoenix Mecano group, PTR Hartmann has established itself as a high-level supplier to the electronics and automotive industries for over 40 years. With 206 parts available on Zenode, engineers can source precision German-engineered connection technology for their designs.
© 2026 Zenode. All rights reserved.
Product families from PTR Hartmann
| Series | Category | Parts | Status | Description |
|---|---|---|---|---|
No series available
This manufacturer doesn't have any product series listed yet. Check back later or contact us if you're looking for specific parts.
Parts from PTR Hartmann that are not part of a series
| Part Information | Pricing (lowest) | Torque - Screw | Operating Temperature (Min) | Operating Temperature (Max) | Clamp Material - Plating | Screw Thread | Screw Material | Housing Material | Mating Orientation | Wire Gauge (AWG) (Min) | Wire Gauge (AWG) (Max) | Mounting Type | Wire Termination | Number of Levels | Voltage | Features | Pitch | Positions Per Level | Current | Color | Voltage - UL | Current - UL | Type | Termination Style | Number of Positions | Wire Gauge or Range - AWG (Max) | Wire Gauge or Range - AWG (Min) | Wire Gauge or Range - mm² (Maximum) | Wire Gauge or Range - mm² (Minimum) | Plug Wire Entry Angle | Contact Material | Screw Size | Wire Strip Length | Insulation Height | Material Flammability Rating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 PTR Hartmann TERM BLK 2POS 5.0MM 0.197" HORIZ | Sign in to see pricing | 0.45 Nm | -40 °C | 105 °C | Steel, Stainless | M3 | Steel | Nylon 6/6, PA66, Polyamide | Vertical with Board | 12 AWG | 22 AWG | Through Hole | Leaf Spring, Screw, Wire Guard | 1 | 300 V | Interlocking (Side) | 0.197 in | 2 | 20 A | Gray | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — |
 PTR Hartmann TERM BLK 2POS 5.0MM 0.197" VERTI | Sign in to see pricing | — | — | — | — | — | — | — | Horizontal with Board | 12 AWG | 22 AWG | Through Hole | Leaf Spring, Screw, Wire Guard | 1 | 300 V | Interlocking (Side) | 0.197 in | 2 | 20 A | Gray | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — |
 PTR Hartmann TERM BLK 3POS 5.0MM 0.197" HORIZ | Sign in to see pricing | — | — | — | — | — | — | — | Vertical with Board | 12 AWG | 22 AWG | Through Hole | Leaf Spring, Screw, Wire Guard | 1 | 300 V | Interlocking (Side) | 0.197 in | 3 | 20 A | Gray | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — |
PTR Hartmann TERM BLK 3POS 5.0MM 0.197" VERTI | Sign in to see pricing | — | — | — | — | — | — | — | Horizontal with Board | 12 AWG | 22 AWG | Through Hole | Leaf Spring, Screw, Wire Guard | 1 | 300 V | Interlocking (Side) | 0.197 in | 3 | 20 A | Gray | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — |
 PTR Hartmann TERM BLK 2POS 7.5MM 0.295" VERTI | Sign in to see pricing | — | — | — | — | — | — | — | Horizontal with Board | 14 AWG | 22 AWG | Through Hole | Leaf Spring, Screw, Wire Guard | 1 | 300 V | Interlocking (Side) | 0.295 in | 2 | 20 A | Gray | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — |
PTR Hartmann TERM BLK 3POS 7.5MM 0.295" VERTI | Sign in to see pricing | — | — | — | — | — | — | — | Horizontal with Board | 14 AWG | 22 AWG | Through Hole | Leaf Spring, Screw, Wire Guard | 1 | 300 V | Interlocking (Side) | 0.295 in | 3 | 20 A | Gray | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — |
 PTR Hartmann TERM BLK PLUG 2POS 5.0MM 0.197" | Sign in to see pricing | 0.5 Nm | -40 °C | 105 °C | — | — | — | Nylon 6/6, PA66, Polyamide | — | — | — | Free Hanging (In-Line) | — | 1 | — | Retention Latches (Wire Side) | 0.197 in | 2 | — | Green | 300 V | 15 A | Female Sockets, Plug | Screw - Rising Cage Clamp | 2 | 28 AWG | 10 AWG | 4 mm² | 0.2 mm² | 90 ° | Bronze | M3 | 7 mm | 1.024 in | UL94 V-0 |
PTR Hartmann TERM BLOCK PLUG 3POS 5MM | Sign in to see pricing | — | -40 °C | 105 °C | — | — | — | — | — | — | — | Free Hanging (In-Line) | — | 1 | — | Retention Latches (Wire Side) | 0.197 in | 3 | — | Green | 300 V | 15 A | Female Sockets, Plug | Screw - Rising Cage Clamp | 3 | 28 AWG | 10 AWG | 4 mm² | 0.2 mm² | 90 ° | — | — | — | — | — |
PTR Hartmann TERM BLOCK PLUG 4POS 5MM | Sign in to see pricing | — | -40 °C | 105 °C | — | — | — | — | — | — | — | Free Hanging (In-Line) | — | 1 | — | Retention Latches (Wire Side) | 0.197 in | 4 | — | Green | 300 V | 15 A | Female Sockets, Plug | Screw - Rising Cage Clamp | 4 | 28 AWG | 10 AWG | 4 mm² | 0.2 mm² | 90 ° | — | — | — | — | — |
PTR Hartmann TERM BLOCK PLUG 5POS 5MM | Sign in to see pricing | — | -40 °C | 105 °C | — | — | — | — | — | — | — | Free Hanging (In-Line) | — | 1 | — | Retention Latches (Wire Side) | 0.197 in | 5 | — | Green | 300 V | 15 A | Female Sockets, Plug | Screw - Rising Cage Clamp | 5 | 28 AWG | 10 AWG | 4 mm² | 0.2 mm² | 90 ° | — | — | — | — | — |
