Product families from Premium PSU
| Series | Category | Parts | Status | Description |
|---|---|---|---|---|
Parts that are not part of a series
© Zenode. All rights reserved.
No series available
This manufacturer doesn't have any product series listed yet. Check back later or contact us if you're looking for specific parts.
Parts from Premium PSU that are not part of a series
| Part Information | Pricing (lowest) | Approval Agency | Voltage - Input (AC) Minimum | Voltage - Input (AC) Maximum | Type | Operating Temperature (Max) | Operating Temperature (Min) | Charge Current - Max | Mounting Type | Battery Chemistry | Power - Max | Termination Style | Size / Dimension Height | Size / Dimension Width | Size / Dimension Length | Voltage - Nominal | Number of Outputs | Standard Number | Current - Output (Max) | Applications | Voltage - Isolation | Voltage - Input (Min) | Efficiency | Voltage - Output 1 | Voltage - Input (Max) | Power (Watts) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Premium PSU BATT CHARGER ENCLOSED 12V 9.6A | Sign in to see pricing | CE, UKCA | 100 VAC | 220 VAC | Enclosed | 70 °C | -25 °C | 9.6 A | Chassis Mount | Lead Acid | 115 W | Terminal Block | 1.65 in | 39.37 in | 8.66 in | 12 V | — | — | — | — | — | — | — | — | — | — |
Premium PSU BATT CHARGER ENCLOSED 24V 4.8A | Sign in to see pricing | CE, UKCA | 100 VAC | 220 VAC | Enclosed | 70 °C | -25 °C | 4.8 A | Chassis Mount | Lead Acid | 115 W | Terminal Block | 1.65 in | 39.37 in | 8.66 in | 24 V | — | — | — | — | — | — | — | — | — | — |
 Premium PSU CRS-240 12/48 TERMINAL CLIP | Sign in to see pricing | CE, UKCA | — | — | Enclosed | 80 °C | -25 °C | — | Chassis Mount | — | — | — | 1.38 in | 3.94 in | 8.66 in | — | 1 | 60950-1, 62368-1 | 4.17 A | ITE (Commercial) | 4200 VDC | 9 V | 82 % | 48 V | 15 V | 200 W |
Premium PSU CRS-240 110/48 TERMINAL BLOCK | Sign in to see pricing | CE, UKCA | — | — | Enclosed | 80 °C | -25 °C | — | Chassis Mount | — | — | — | 1.38 in | 3.94 in | 8.66 in | — | 1 | 60950-1, 62368-1 | 5.8 A | ITE (Commercial) | 4200 VDC | 77 V | 92 % | 48 V | 144 V | 278 W |
 Premium PSU CRS-500 24/24 T | Sign in to see pricing | CE, UKCA | — | — | Enclosed | 70 °C | -25 °C | — | Chassis Mount | — | — | — | 2.16 in | 7.09 in | 10.47 in | — | 1 | 60950-1, 62368-1 | 20.8 A | ITE (Commercial) | 4200 VDC | 14.4 V | 92 % | 24 V | 30 V p-p | 499 W |
 Premium PSU CRS-1000 110/24V 2FANS, ORING | Sign in to see pricing | CE, UKCA | — | — | Enclosed | 70 °C | -25 °C | — | Chassis Mount | — | — | — | 2.16 in | 8.98 in | 10.55 in | — | 1 | 60950-1, 62368-1 | 41.6 A | ITE (Commercial) | 4200 VDC | 66 V | 92 % | 24 V | 144 V | 998 W |
 Premium PSU CRS-1000 110/24V 2 FANS ORING HO | Sign in to see pricing | CE, UKCA | — | — | Enclosed | 70 °C | -25 °C | — | Chassis Mount | — | — | — | 2.16 in | 8.98 in | 10.55 in | — | 1 | 60950-1, 62368-1 | 41.6 A | ITE (Commercial) | 4200 VDC | 66 V | 92 % | 24 V | 144 V | 998 W |
Premium PSU CRS-1000 110/24V 4 FAN, ORING | Sign in to see pricing | CE, UKCA | — | — | Enclosed | 70 °C | -25 °C | — | Chassis Mount | — | — | — | 2.16 in | 8.98 in | 10.55 in | — | 1 | 60950-1, 62368-1 | 41.6 A | ITE (Commercial) | 4200 VDC | 66 V | 92 % | 24 V | 144 V | 998 W |
Premium PSU CRS-1000 24/110 2 FANS ORING HOL | Sign in to see pricing | CE, UKCA | — | — | Enclosed | 70 °C | -25 °C | — | Chassis Mount | — | — | — | 2.16 in | 8.98 in | 10.55 in | — | 1 | 60950-1, 62368-1 | 9.8 A | ITE (Commercial) | 4200 VDC | 14.4 V | 90 % | 110 V | 30 V p-p | 1078 W |
 Premium PSU CTS-240 110/12V RAILWAY CLIP TER | Sign in to see pricing | CE, UKCA | — | — | Enclosed | 85 °C | -25 °C | — | Chassis Mount | — | — | — | 1.38 in | 3.94 in | 8.66 in | — | 1 | 60950-1, 62368-1 | 20 A | ITE (Commercial) | 4200 VDC | 66 V | 88 % | 12 V | 144 V | 240 W |
