Product families from PCA Electronics, Inc.
| Series | Category | Parts | Status | Description |
|---|---|---|---|---|
Parts that are not part of a series
© Zenode. All rights reserved.
No series available
This manufacturer doesn't have any product series listed yet. Check back later or contact us if you're looking for specific parts.
Parts from PCA Electronics, Inc. that are not part of a series
| Part Information | Pricing (lowest) | Turns Ratio - Primary | Turns Ratio - Secondary | ET (Volt-Time) | Size / Dimension Length | Size / Dimension Width | Transformer Type | Operating Temperature (Min) | Operating Temperature (Max) | Height - Seated (Max) | Inductance | Mounting Type | Chipset Manufacturer | Voltage - Primary (Max) | Voltage - Primary (Min) | Frequency | Voltage - Isolation | Footprint Length | Footprint Width | Voltage - Auxiliary | Type | Intended Chipset | Applications | Voltage - Primary | Frequency (Max) | Frequency (Min) | Turns Ratio - Primary (Receiver) | Turns Ratio Mode | Turns Ratio - Secondary (Receiver) | Turns Ratio - Secondary (Transmitter) | Turns Ratio - Primary (Transmitter) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 PCA Electronics, Inc. ISOLATED GATE DRIVE | Sign in to see pricing | 1 | 1 | 9.7 VµS | 0.265 in | 0.34 in | Gate Drive | -40 °C | 85 °C | 0.098 in | 785 µH | Surface Mount | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — |
 PCA Electronics, Inc. XFMR FLYBCK DC/DC CONV 37.5UH SM | Sign in to see pricing | — | — | — | — | — | — | -40 °C | 85 °C | 12.7 mm | 37.5 µH | Surface Mount | Analog Devices | 57 V | 36 V | 250 kHz | 1500 Vrns | 0.55 in | 0.669 in | 3.3 V | For DC/DC Converters | LT42691 | Flyback Converters | — | — | — | — | — | — | — | — |
 PCA Electronics, Inc. XFMR FLYBACK DC/DC CONV 39UH SMD | Sign in to see pricing | — | — | — | — | — | — | -40 °C | 85 °C | 12.7 mm | 39 µH | Surface Mount | Analog Devices | 57 V | 36 V | 250 kHz | 1500 Vrns | 0.55 in | 0.669 in | 5 V | For DC/DC Converters | LT42691 | Flyback Converters | — | — | — | — | — | — | — | — |
 PCA Electronics, Inc. XFMR FLYBACK DC/DC CONV 37UH SMD | Sign in to see pricing | — | — | — | — | — | — | -40 °C | 85 °C | 12.7 mm | 37 µH | Surface Mount | Analog Devices | 57 V | 36 V | 250 kHz | 1500 Vrns | 0.55 in | 0.669 in | 12 V | For DC/DC Converters | LT42691 | Flyback Converters | — | — | — | — | — | — | — | — |
 PCA Electronics, Inc. XFMR FLYBACK DC/DC CONV 9UH SMD | Sign in to see pricing | — | — | — | — | — | — | -40 °C | 85 °C | 0.453 in | 9 µH | Surface Mount | Analog Devices | 57 V | 9 V | 250 kHz | 1500 Vrns | 0.866 in | 1.14 in | 5 V | For DC/DC Converters | LTC4278 | Flyback Converters | — | — | — | — | — | — | — | — |
 PCA Electronics, Inc. XFMR FWD CON DC/DC CON 180UH SM | Sign in to see pricing | — | — | — | — | — | — | -40 °C | 125 °C | 0.453 in | 180 µH | Surface Mount | Analog Devices | 57 V | 33 V | 200 kHz | 1500 Vrns | 0.83 in | 1.14 in | 12 V | For DC/DC Converters | LT4276A, LT4295 | Forward Converters | — | — | — | — | — | — | — | — |
 PCA Electronics, Inc. XFMR FLYBACK DC/DC CONV 15UH SMD | Sign in to see pricing | — | — | — | — | — | — | -40 °C | 125 °C | 0.54 in | 15 µH | Surface Mount | Analog Devices | 57 V | 40 V | 250 kHz | 1500 Vrns | 1.036 in | 1.25 in | 24 V | For DC/DC Converters | LT4295 | Flyback Converters | — | — | — | — | — | — | — | — |
 PCA Electronics, Inc. POE FLYBACK XFM 12V, 36W | Sign in to see pricing | — | — | — | — | — | — | -40 °C | 85 °C | 0.485 in | 26 µH | Surface Mount | Analog Devices | 57 V | 42 V | 250 kHz | 1500 Vrns | 0.55 in | 0.695 in | 12 V | For DC/DC Converters | LT4295 | Flyback Converters | — | — | — | — | — | — | — | — |
 PCA Electronics, Inc. XFMR P-P DC/DC CONV 1MH SMD | Sign in to see pricing | — | — | — | — | — | — | -40 °C | 125 °C | 0.165 in | 1000 µH | Surface Mount | Texas Instruments | — | — | — | 2500 Vrms | 0.276 in | 0.433 in | 5 V | For DC/DC Converters | SN6501, SN6505B | Push-Pull Converters | 5 V | 620 kHz | 300 | — | — | — | — | — |
 PCA Electronics, Inc. POE DATA XFM, 1.15A | Sign in to see pricing | — | — | — | 0.71 in | 0.6 in | LAN 10/100/1000 Base-T, Power over Ethernet (PoE) | -40 °C | 85 °C | 0.4 in | 350 µH | Surface Mount | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 1 CT | Receiver, Transmitter | 1 | 1 CT | 1 CT |
