Product families from Nominal Controls
| Series | Category | Parts | Status | Description |
|---|---|---|---|---|
Parts that are not part of a series
© Zenode. All rights reserved.
| Series | Category | Parts | Status | Description |
|---|---|---|---|---|
| Solid State Relays (SSR) | 1 | Active |
Parts from Nominal Controls that are not part of a series
| Part Information | Pricing (lowest) | Package / Case | Voltage - Input (DC) Minimum | Voltage - Input (DC) Maximum | Voltage - Load (Min) | Voltage - Load (Max) | Output Type | Termination Style | Mounting Type | Circuit | Load Current | Package Name | On-State Resistance (Max) | Operating Temperature (Min) | Operating Temperature (Max) | Approval Agency |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Nominal Controls DC-OUT SSC 100V/400A | Sign in to see pricing | Hockey Puck | 12 V | 32 VDC | 1 V | 100 V | DC | Busbar | Chassis Mount | SPST-NO (1 Form A) | 400 A | — | — | — | — | — |
 Nominal Controls DC-OUT SSC 100V/400A | Sign in to see pricing | Hockey Puck | 12 V | 24 V | 1 V | 100 V | DC | Busbar | Chassis Mount | SPST-NO (1 Form A) | 400 A | — | — | — | — | — |
 Nominal Controls DC-SSR 100V/500A | Sign in to see pricing | Module | 12 V | 24 V | 1 V | 100 V | DC | Busbar | Panel Mount | SPST-NO (1 Form A) | 500 A | Module | 0.5 mOhms | — | — | — |
 Nominal Controls DC-OUT SSC 600V/120A | Sign in to see pricing | Hockey Puck | 12 V | 24 V | 1 V | 600 V | DC | Busbar | Chassis Mount | SPST-NO (1 Form A) | 120 A | — | — | — | — | — |
Nominal Controls DC-OUT SSC 600V/200A | Sign in to see pricing | Hockey Puck | 12 V | 32 VDC | 1 V | 600 V | DC | Busbar | Chassis Mount | SPST-NO (1 Form A) | 200 A | — | — | — | — | — |
Nominal Controls DC-OUT SSC 600V/200A | Sign in to see pricing | Hockey Puck | 12 V | 24 V | 1 V | 600 V | DC | Busbar | Chassis Mount | SPST-NO (1 Form A) | 200 A | — | — | — | — | — |
Nominal Controls DC-OUT SSC 1KV/150A | Sign in to see pricing | Module | 12 V | 24 V | 1 V | 1000 V | DC | Busbar | Chassis Mount | SPST-NO (1 Form A) | 150 A | — | — | — | — | — |
Nominal Controls DC-OUT SSC 1KV/250A | Sign in to see pricing | Hockey Puck | 12 V | 32 VDC | 1 V | 1000 V | DC | Busbar | Chassis Mount | SPST-NO (1 Form A) | 250 A | — | — | — | — | — |
Nominal Controls DC-OUT SSC 1KV/250A | Sign in to see pricing | Module | 12 V | 24 V | 1 V | 1000 V | DC | Busbar | Chassis Mount | SPST-NO (1 Form A) | 250 A | — | — | — | — | — |
 Nominal Controls 100V/60A DC REVERSING SSR | Sign in to see pricing | Hockey Puck | 12 V | 24 V | 0 V | 100 V | DC | Screw Terminal | Panel Mount | SPST-NO (1 Form A) | 60 A | Hockey Puck | 6 mOhms | -40 °C, -30 °C | 55 °C, 80 °C | CE |
