Product families from MDT
| Series | Category | Parts | Status | Description |
|---|---|---|---|---|
Parts that are not part of a series
© Zenode. All rights reserved.
No series available
This manufacturer doesn't have any product series listed yet. Check back later or contact us if you're looking for specific parts.
Parts from MDT that are not part of a series
| Part Information | Pricing (lowest) | Operating Temperature (Max) | Operating Temperature (Min) | Package / Case | Current - Supply (Max) | Package Name | Current - Output (Max) | Mounting Type | Output Type | Function | Test Condition | Voltage - Supply (Maximum) | Voltage - Supply (Minimum) | Sensing Range (Trip) | Sensing Range (Release) | Technology | Features | Package Width | Package Length | Polarization | Output | For Measuring | Output Signal | Termination Style | Resistance | Rotation Angle - Electrical, Mechanical (Minimum) | Rotation Angle - Electrical, Mechanical (Maximum) | Voltage - Supply | Actuator Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 MDT AMR SENSOR MAG SW 360DEG 17G 1UA | Sign in to see pricing | 125 °C | -40 °C | SC-59, SOT-23-3, TO-236-3 | 1 A | SOT-23-3 | 9 mA | Surface Mount | Push-Pull | Omnipolar Switch | 77 °F | 5.5 V | 1.8 V | 25 mT | -20 mT | Magnetoresistive | — | — | — | — | — | — | — | — | — | — | — | — | — |
 MDT AMR SW OMNI 15G 1.6-5V ACTIVE-HI | Sign in to see pricing | 125 °C | -40 °C | 3-PowerUDFN | 40 µA | 3-DFN | 20 mA | Surface Mount | CMOS | Latch, Omnipolar Switch | 77 °F | 5 V | 1.6 V | 1.5 mT | 1 mT | Magnetoresistive | Temperature Compensated | 2 mm | 2 mm | North Pole, South Pole | — | — | — | — | — | — | — | — | — |
 MDT AMR SW OMNI 15G 1.6-5V ACTIVE-HI | Sign in to see pricing | 125 °C | -40 °C | 3-WFLGA | 40 µA | 3-LGA | 20 mA | Surface Mount | CMOS | Latch, Omnipolar Switch | 77 °F | 5 V | 1.6 V | 1.5 mT | 1 mT | Magnetoresistive | Temperature Compensated | 1.5 mm | 2 mm | North Pole, South Pole | — | — | — | — | — | — | — | — | — |
 MDT AMR SW OMNI 27G 1.6-5V ACTIVE-HI | Sign in to see pricing | 125 °C | -40 °C | 3-PowerUDFN | 40 µA | 3-DFN | 20 mA | Surface Mount | CMOS | Latch, Omnipolar Switch | 77 °F | 5 V | 1.6 V | 3.5 mT | 2.7 mT | Magnetoresistive | Temperature Compensated | 2 mm | 2 mm | North Pole, South Pole | — | — | — | — | — | — | — | — | — |
 MDT AMR SW OMNI 27G 1.6-5V ACTIVE-HI | Sign in to see pricing | 125 °C | -40 °C | 3-WFLGA | 40 µA | 3-LGA | 20 mA | Surface Mount | CMOS | Latch, Omnipolar Switch | 77 °F | 5 V | 1.6 V | 3.5 mT | 2.7 mT | Magnetoresistive | Temperature Compensated | 1.5 mm | 2 mm | North Pole, South Pole | — | — | — | — | — | — | — | — | — |
 MDT AMR SENSOR ANGLE DUAL 180DEG | Sign in to see pricing | 125 °C | -40 °C | 8-VLGA | — | 8-LGA | — | Surface Mount | — | — | — | — | — | — | — | Magnetoresistive | — | 5 mm | 5 mm | — | Wheatstone Bridge | Angle | Cosine, Sine | SMD (SMT) Tab | 4.2 kOhm | 0 ° | 180 ° | 18 VDC | External Magnet, Not Included |
 MDT AMR SENSOR ANGLE DUAL 180DEG | Sign in to see pricing | 125 °C | -40 °C | — | — | 8-SOIC, 8-SOP | — | Surface Mount | — | — | — | 18 V | 0 V | — | — | Magnetoresistive | — | 3.9 mm | 0.154 in | — | Wheatstone Bridge | Angle, Rotary | Cosine, Sine | SMD (SMT) Tab | 4.2 kOhm | 0 ° | 180 ° | — | External Magnet, Not Included |
 MDT AMR SENSOR ANGLE ON/OFF AXIS | Sign in to see pricing | 125 °C | -40 °C | 12-WDFN Exposed Pad | — | 12-DFN | — | Surface Mount | — | — | — | — | — | — | — | Magnetoresistive | — | 2 mm | 6 mm | — | Analog Voltage | Angle, Linear | Cosine, Sine | SMD (SMT) Tab | 2.7 kOhm | — | — | 5 VDC | External Magnet, Not Included |
 MDT TMR SENSOR MAG SW UNI 17G 1.5UA | Sign in to see pricing | 125 °C | -40 °C | SC-59, SOT-23-3, TO-236-3 | 1.5 µA | SOT-23-3 | 20 mA | Surface Mount | Push-Pull | Latch, Unipolar Switch | 77 °F | 5.5 V | 1.8 V | 1.7 mT | 1.3 mT | Magnetic, Magnetoresistive, TMR (Tunneling Magnetoresistive) | Temperature Compensated | — | — | North Pole, South Pole | — | — | — | — | — | — | — | — | — |
 MDT TMR SENSOR MAG SW UNI 17G 200NA | Sign in to see pricing | 125 °C | -40 °C | SC-59, SOT-23-3, TO-236-3 | 200 nA | SOT-23-3 | 20 mA | Surface Mount | Open Drain | Unipolar Switch | 77 °F | 5.5 V | 1.8 V | 1.7 mT | 1.3 mT | Magnetic, Magnetoresistive, TMR (Tunneling Magnetoresistive) | Temperature Compensated | — | — | North Pole | — | — | — | — | — | — | — | — | — |
