MDE Semiconductor is an innovative manufacturer specializing in TVS diodes and circuit protection products, offering high-current surge protection solutions for aerospace, defense, medical, and industrial applications.
Parts that are not part of a series
Company background and product focus
MDE Semiconductor, Inc. is a quality-oriented manufacturer with a focused expertise in circuit protection products. As a market leader in transient voltage suppression technology, MDE offers a comprehensive range of standard and high-current TVS diodes, thyristors, and varistors designed to protect electronic systems from destructive transients.
MDE's Transient Voltage Suppressor Diodes are specifically engineered to protect against:
All MDE silicon devices utilize their renowned low-leakage glass passivation process, delivering exceptional energy absorption capability ranging from 400 watts to 288,000 watts. Their products meet rigorous industry standards including RTCA/DO-160 and MIL-STD requirements, ensuring reliable performance in aerospace, defense, industrial, medical, and telecommunications applications where component reliability is mission-critical.
© 2026 Zenode. All rights reserved.
Product families from MDE Semiconductor Inc
| Series | Category | Parts | Status | Description |
|---|---|---|---|---|
Parts from MDE Semiconductor Inc that are not part of a series
| Part Information | Pricing (lowest) | Voltage - Breakdown (Min) | Current - Peak Pulse | Power Line Protection | Operating Temperature (Min) | Operating Temperature (Max) | Mounting Type | Applications | Voltage - Clamping (Max) | Type | Voltage - Reverse Standoff (Typ) | Unidirectional Channels | Power - Peak Pulse | Package Name | Package / Case | Bidirectional Channels |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 MDE Semiconductor Inc TVS DIODE UP 100VRWM 161.3VC | Sign in to see pricing | 111.7 V | 93.6 A | No | -55 °C | 175 °C | Through Hole | General Purpose | 161.3 V | Zener | 100 V | 1 | 15000 W | P600 | Axial, P600 | — |
MDE Semiconductor Inc TVS DIODE BP 100VRWM 161.3VC | Sign in to see pricing | 111.7 V | 93.6 A | No | -55 °C | 175 °C | Through Hole | General Purpose | 161.3 V | Zener | 100 V | — | 15000 W | P600 | Axial, P600 | 1 |
MDE Semiconductor Inc TVS DIODE UP 110VRWM 178.6VC | Sign in to see pricing | 122.9 V | 84.5 A | No | -55 °C | 175 °C | Through Hole | General Purpose | 178.6 V | Zener | 110 V | 1 | 15000 W | P600 | Axial, P600 | — |
MDE Semiconductor Inc TVS DIODE BP 110VRWM 178.6VC | Sign in to see pricing | 122.9 V | 84.5 A | No | -55 °C | 175 °C | Through Hole | General Purpose | 178.6 V | Zener | 110 V | — | 15000 W | P600 | Axial, P600 | 1 |
MDE Semiconductor Inc TVS DIODE UP 120VRWM 192.3VC | Sign in to see pricing | 134 V | 78.5 A | No | -55 °C | 175 °C | Through Hole | General Purpose | 192.3 V | Zener | 120 V | 1 | 15000 W | P600 | Axial, P600 | — |
MDE Semiconductor Inc TVS DIODE BP 120VRWM 192.3VC | Sign in to see pricing | 134 V | 78.5 A | No | -55 °C | 175 °C | Through Hole | General Purpose | 192.3 V | Zener | 120 V | — | 15000 W | P600 | Axial, P600 | 1 |
MDE Semiconductor Inc TVS DIODE UP 130VRWM 208.3VC | Sign in to see pricing | 145.2 V | 72.5 A | No | -55 °C | 175 °C | Through Hole | General Purpose | 208.3 V | Zener | 130 V | 1 | 15000 W | P600 | Axial, P600 | — |
MDE Semiconductor Inc TVS DIODE BP 130VRWM 208.3VC | Sign in to see pricing | 145.2 V | 72.5 A | No | -55 °C | 175 °C | Through Hole | General Purpose | 208.3 V | Zener | 130 V | — | 15000 W | P600 | Axial, P600 | 1 |
MDE Semiconductor Inc TVS DIODE UP 150VRWM 241.9VC | Sign in to see pricing | 167.6 V | 62.4 A | No | -55 °C | 175 °C | Through Hole | General Purpose | 241.9 V | Zener | 150 V | 1 | 15000 W | P600 | Axial, P600 | — |
MDE Semiconductor Inc TVS DIODE BP 150VRWM 241.9VC | Sign in to see pricing | 167.6 V | 62.4 A | No | -55 °C | 175 °C | Through Hole | General Purpose | 241.9 V | Zener | 150 V | — | 15000 W | P600 | Axial, P600 | 1 |
