GAPTEC Electronic is a German manufacturer specializing in isolated and non-isolated DC-DC converters, AC-DC power supplies, and POL modules for industrial, medical, telecom, and transportation applications.
Parts that are not part of a series
Company background and product focus
GAPTEC Electronic, founded in 2010 and headquartered in Langen, Germany, specializes in isolated and non-isolated voltage converters and power modules. The company supplies a carefully selected range of AC-DC and DC-DC converters with industrial-standard voltages and pin configurations.
GAPTEC's power supply portfolio includes:
With ISO 9001:2015 certification and products meeting UL62368, UL60950, EN50155, and UL60601 standards, GAPTEC Electronic offers OEMs short lead times and a 3-year warranty through certified manufacturing partnerships in Taiwan and China.
© 2026 Zenode. All rights reserved.
Product families from GAPTEC Electronic
| Series | Category | Parts | Status | Description |
|---|---|---|---|---|
No series available
This manufacturer doesn't have any product series listed yet. Check back later or contact us if you're looking for specific parts.
Parts from GAPTEC Electronic that are not part of a series
| Part Information | Pricing (lowest) | Number of Outputs | Voltage - Input (Min) | Current - Output (Max) | Type | Voltage - Isolation | Voltage - Input (Max) | Package Leads | Package Name | Size / Dimension Height | Size / Dimension Width | Size / Dimension Length | Voltage - Output 1 | Mounting Type | Power (Watts) | Efficiency | Applications | Operating Temperature (Max) | Operating Temperature (Min) | Voltage - Output 2 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 GAPTEC Electronic ISOLATED MODULE DC DC CONVERTERS | Sign in to see pricing | 1 | 2.9 V | 30.3 mA | Isolated Module | 3 kV | 3.6 V | 5 Leads | 14-DIP Module | 0.27 in | 0.39 in | 0.77 in | 3.3 V | Through Hole | 100 mW | 72 % | ITE (Commercial) | 105 °C | -40 °C | — |
GAPTEC Electronic ISOLATED MODULE DC DC CONVERTERS | Sign in to see pricing | 1 | 2.9 V | 20 mA | Isolated Module | 3 kV | 3.6 V | 5 Leads | 14-DIP Module | 0.27 in | 0.39 in | 0.77 in | 5 V | Through Hole | 100 mW | 72 % | ITE (Commercial) | 105 °C | -40 °C | — |
GAPTEC Electronic ISOLATED MODULE DC DC CONVERTERS | Sign in to see pricing | 2 | 4.4 V | 10 mA | Isolated Module | 3 kV | 5.6 V | 6 Leads | 14-DIP Module | 0.27 in | 0.39 in | 0.77 in | 5 V | Through Hole | 100 mW | 72 % | ITE (Commercial) | 105 °C | -40 °C | -5 V |
GAPTEC Electronic ISOLATED MODULE DC DC CONVERTERS | Sign in to see pricing | 1 | 4.4 V | 20 mA | Isolated Module | 3 kV | 5.6 V | 5 Leads | 14-DIP Module | 0.27 in | 0.39 in | 0.77 in | 5 V | Through Hole | 100 mW | 72 % | ITE (Commercial) | 105 °C | -40 °C | — |
GAPTEC Electronic ISOLATED MODULE DC DC CONVERTERS | Sign in to see pricing | 2 | 4.4 V | 5.55 mA | Isolated Module | 3 kV | 5.6 V | 6 Leads | 14-DIP Module | 0.27 in | 0.39 in | 0.77 in | 9 V | Through Hole | 100 mW | 77 % | ITE (Commercial) | 105 °C | -40 °C | -9 V |
GAPTEC Electronic ISOLATED MODULE DC DC CONVERTERS | Sign in to see pricing | 1 | 4.4 V | 11.1 mA | Isolated Module | 3 kV | 5.6 V | 5 Leads | 14-DIP Module | 0.27 in | 0.39 in | 0.77 in | 9 V | Through Hole | 100 mW | 75 % | ITE (Commercial) | 105 °C | -40 °C | — |
GAPTEC Electronic ISOLATED MODULE DC DC CONVERTERS | Sign in to see pricing | 2 | 4.4 V | 4.15 mA | Isolated Module | 3 kV | 5.6 V | 6 Leads | 14-DIP Module | 0.27 in | 0.39 in | 0.77 in | 12 V | Through Hole | 100 mW | 78 % | ITE (Commercial) | 105 °C | -40 °C | -12 V |
GAPTEC Electronic ISOLATED MODULE DC DC CONVERTERS | Sign in to see pricing | 1 | 4.4 V | 8.3 mA | Isolated Module | 3 kV | 5.6 V | 5 Leads | 14-DIP Module | 0.27 in | 0.39 in | 0.77 in | 12 V | Through Hole | 100 mW | 76 % | ITE (Commercial) | 105 °C | -40 °C | — |
GAPTEC Electronic ISOLATED MODULE DC DC CONVERTERS | Sign in to see pricing | 2 | 4.4 V | 3.35 mA | Isolated Module | 3 kV | 5.6 V | 6 Leads | 14-DIP Module | 0.27 in | 0.39 in | 0.77 in | 15 V | Through Hole | 101 mW | 80 % | ITE (Commercial) | 105 °C | -40 °C | -15 V |
GAPTEC Electronic ISOLATED MODULE DC DC CONVERTERS | Sign in to see pricing | 1 | 4.4 V | 6.7 mA | Isolated Module | 3 kV | 5.6 V | 5 Leads | 14-DIP Module | 0.27 in | 0.39 in | 0.77 in | 15 V | Through Hole | 101 mW | 78 % | ITE (Commercial) | 105 °C | -40 °C | — |
