Diodes Inc

Series	Category	# Parts	Status	Description

Part	Spec A	Spec B	Spec C	Spec D	Description

Standalone parts(5404)

...

Part	Category	Description
Diodes Inc ZXSC100X8TAObsolete	Integrated Circuits (ICs)	SWITCHING CONTROLLER, VOLTAGE-MODE, 200KHZ SWITCHING FREQ-MAX, PDSO8, MSOP-8
Diodes Inc MBR1045Obsolete	Discrete Semiconductor Products	DIODE SCHOTTKY 45V 10A TO220AC
Diodes Inc BC847CQ-7-F	Discrete Semiconductor Products	TRANS GP BJT NPN 45V 0.1A 3-PIN SOT-23 T/R
Diodes Inc FL2500151	Crystals Oscillators Resonators	CRYSTAL 25MHZ FUND 60OHM 4-PIN MINI-CSMD
Diodes Inc FDD300004	Crystals Oscillators Resonators	XTAL OSC XO 133.0000MHZ CMOS SMD
Diodes Inc 1N4002G-T	Discrete Semiconductor Products	DIODE GEN PURP 100V 1A DO41
Diodes Inc MBRF20150CTLObsolete	Discrete Semiconductor Products	DIODE SCHOTTKY ITO220AB
Diodes Inc AP9101CAK-BUTRG1	Integrated Circuits (ICs)	NRND = NOT RECOMMENDED FOR NEW DESIGN
Diodes Inc RS1MWF-7	Discrete Semiconductor Products	1.1V@2A 240NS INDEPENDENT TYPE 1A 1KV SOD-123F FAST RECOVERY / HIGH EFFICIENCY DIODES ROHS
Diodes Inc 74LVC1G3157DW-7	Integrated Circuits (ICs)	ANALOGUE SW, SPDT, -40 TO 125DEG C ROHS COMPLIANT: YES

Series	Category	# Parts	Status	Description

AP5727White LED Step-Up Converter	Power Management - Specialized	1	Active	The AP5727 is a high efficiency boost converter in a compact SOT25 that provides the bias voltages for OLED Sub Display and TFT-LCD (Liquid Crystal Display). A high 1.2MHz switching frequency and internal compensation minimizes external part count, PCB area and cost. Integrated soft start reduces inrush current. The AP5727 has a 1.25V feedback voltage making it compatible with industry standard boost converters used to bias LCD panels.
AP61062	Voltage Regulators - DC DC Switching Regulators	1	Active
AP61100QAUTOMOTIVE-COMPLIANT, 2.3V TO 5.5V INPUT, 1A LOW IQ SYNCHRONOUS BUCK CONVERTER	PMIC	2	Active	The AP61100/AP61102 is a 1A, synchronous buck converter with a wide input voltage range of 2.3V to 5.5V. The device fully integrates a 110mΩ high-side power MOSFET and an 80mΩ low-side power MOSFET to provide high-efficiency step-down DC-DC conversion. The AP61100/AP61102 device is easily used by minimizing the external component count due to its adoption of Constant On-Time (COT) control to achieve fast transient response, easy loop stabilization, and low output voltage ripple. The device is available in a SOT563 package.
AP61102QAUTOMOTIVE-COMPLIANT, 2.3V TO 5.5V INPUT, 1A LOW IQ SYNCHRONOUS BUCK CONVERTER with PG	Evaluation Boards	2	Active	The AP61100Q/AP61102Q is an automotive-compliant, 1A, synchronous buck converter with a wide input voltage range of 2.3V to 5.5V. The device fully integrates a 110mΩ high-side power MOSFET and an 80mΩ low-side power MOSFET to provide high-efficiency stepdown DC-DC conversion.
AP612002.3V TO 5.5V INPUT, 2A LOW IQ SYNCHRONOUS BUCK CONVERTER	Integrated Circuits (ICs)	1	Active	The DIODES™ AP61200 / DIODES™ AP61201 / DIODES™ AP61202 / DIODES™ AP61203 is a 2A, synchronous buck converter with a wide input voltage range of 2.3V to 5.5V. The device fully integrates a 110mΩ high-side power MOSFET and an 80mΩ low-side power MOSFET to provide high-efficiency step-down DC-DC conversion.
AP612012.3V TO 5.5V INPUT, 2A LOW IQ SYNCHRONOUS BUCK CONVERTER	Power Management (PMIC)	1	Active	The DIODES™ AP61200 / DIODES™ AP61201 / DIODES™ AP61202 / DIODES™ AP61203 is a 2A, synchronous buck converter with a wide input voltage range of 2.3V to 5.5V. The device fully integrates a 110mΩ high-side power MOSFET and an 80mΩ low-side power MOSFET to provide high-efficiency step-down DC-DC conversion.
AP612022.3V TO 5.5V INPUT, 2A LOW IQ SYNCHRONOUS BUCK CONVERTER	Power Management (PMIC)	1	Active	The DIODES™ AP61200 / DIODES™ AP61201 / DIODES™ AP61202 / DIODES™ AP61203 is a 2A, synchronous buck converter with a wide input voltage range of 2.3V to 5.5V. The device fully integrates a 110mΩ high-side power MOSFET and an 80mΩ low-side power MOSFET to provide high-efficiency step-down DC-DC conversion.
AP612032.3V TO 5.5V INPUT, 2A LOW IQ SYNCHRONOUS BUCK CONVERTER	Integrated Circuits (ICs)	1	Active	The DIODES™ AP61200 / DIODES™ AP61201 / DIODES™ AP61202 / DIODES™ AP61203 is a 2A, synchronous buck converter with a wide input voltage range of 2.3V to 5.5V. The device fully integrates a 110mΩ high-side power MOSFET and an 80mΩ low-side power MOSFET to provide high-efficiency step-down DC-DC conversion.
AP61300	Power Management (PMIC)	2	Active
AP621504.2V TO 18V INPUT, 1.5A LOW IQ SYNCHRONOUS BUCK CONVERTER	Evaluation Boards	1	Active	The AP62150 is a 1.5A, synchronous buck converter with a wide input voltage range of 4.2V to 18V. The device fully integrates a 90mΩ highside power MOSFET and a 65mΩ low-side power MOSFET to provide high-efficiency step-down DC-DC conversion.
