Product families from CAMBION
| Series | Category | Parts | Status | Description |
|---|---|---|---|---|
Parts that are not part of a series
© Zenode. All rights reserved.
No series available
This manufacturer doesn't have any product series listed yet. Check back later or contact us if you're looking for specific parts.
Parts from CAMBION that are not part of a series
| Part Information | Pricing (lowest) | Features | Operating Temperature (Max) | Operating Temperature (Min) | Termination | Length - Overall | Socket Depth | Accepts Pin Diameter (Max) | Accepts Pin Diameter (Min) | Contact Finish | Contact Finish Thickness | Flange Diameter | Contact Material | Mounting Hole Diameter | Accepts Pin Diameter |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 CAMBION SOCKET | Sign in to see pricing | Closed Bottom | 125 °C | -55 °C | Press-Fit | 0.213 in | 0.2 in | 0.062 in | 0.06 in | Gold | 30 µin | 0.12 in | Beryllium Copper | 0.102 in | — |
 CAMBION TURRET SOLDER / PRESS MOUNT TERMINAL, INSULATED, 2.59 MM, GOLD, 7.29 MM, 4.11 MM | Sign in to see pricing | Closed Bottom | 125 °C | -55 °C | Solder | 0.287 in | 0.25 in | 0.062 in | 0.06 in | Gold | 30 µin | 0.2 in | Beryllium Copper | 0.102 in | — |
 CAMBION TURRET SOLDER / PRESS MOUNT TERMINAL, NON INSULATED, 2.59 MM, GOLD, 5.41 MM, 4.95 MM | Sign in to see pricing | — | — | — | Solder | 0.213 in | 0.2 in | 0.062 in | 0.06 in | Gold | 30 µin | 0.12 in | Beryllium Copper | 0.102 in | — |
 CAMBION TURRET SOLDER / PRESS MOUNT TERMINAL, NON INSULATED, 1.4 MM, GOLD, 4.12 MM, 3.61 MM | Sign in to see pricing | — | — | — | Solder | 0.162 in | 0.141 in | — | — | Gold | 30 µin | 0.074 in | Beryllium Copper | 0.055 in | 0.025 in |
CAMBION TURRET SOLDER / PRESS MOUNT TERMINAL, NON INSULATED, 1.93 MM, GOLD, 5.24 MM, 4.78 MM | Sign in to see pricing | — | — | — | Solder | 0.202 in | 0.19 in | — | — | Gold | 30 µin | 0.09 in | Beryllium Copper | 0.076 in | 0.04 in |
 CAMBION SOCKET | Sign in to see pricing | Knockout Bottom | 125 °C | -55 °C | Solder | 0.202 in | 0.19 in | — | — | Gold | 30 µin | 0.09 in | Beryllium Copper | 0.076 in | 0.04 in |
CAMBION SOCKET | Sign in to see pricing | — | — | — | Solder | 0.202 in | 0.19 in | 0.032 in | 0.03 in | Gold | 30 µin | 0.09 in | Beryllium Copper | 0.076 in | — |
 CAMBION SOCKET | Sign in to see pricing | — | — | — | Press-Fit | 0.202 in | 0.19 in | — | — | Gold | 30 µin | 0.09 in | Beryllium Copper | 0.076 in | 0.04 in |
 CAMBION TURRET SOLDER / PRESS MOUNT TERMINAL, NON INSULATED, 1.32 MM, GOLD, 5.76 MM, 5.38 MM | Sign in to see pricing | — | — | — | Solder | 0.227 in | 0.207 in | 0.02 in | 0.016 in | Gold | 30 µin | 0.06 in | Beryllium Copper | 0.052 in | — |
CAMBION SOCKET | Sign in to see pricing | — | — | — | Solder | 0.227 in | — | 0.02 in | 0.016 in | Gold | 30 µin | 0.06 in | Beryllium Copper | 0.052 in | — |
