The LTC3630A is a high efficiency step-down DC/DC converter with internal high side and synchronous power switches that draws only 12μA typical DC supply current while maintaining a regulated output voltage at no load.The LTC3630A can supply up to 500mA load current and features a programmable peak current limit that provides a simple method for optimizing efficiency and for reducing output ripple and component size. The LTC3630A’s combination of Burst Mode®operation, integrated power switches, low quiescent current, and programmable peak current limit provides high efficiency over a broad range of load currents.With its wide input range of 4V to 76V, the LTC3630A is a robust converter suited for regulating a wide variety of power sources. A feedback comparator output enables multiple LTC3630As to be paralleled in higher current applications.The LTC3630A is available in the thermally-enhanced 3mm × 5mm DFN and the MSE16 packages.Vin RangeLTC36304.5V to 65VLTC3630A4.5V to 76VAPPLICATIONSIndustrial Control SuppliesMedical DevicesPortable InstrumentsAutomotiveAvionics

The LTC3630A is a high efficiency step-down DC/DC converter with internal high side and synchronous power switches that draws only 12μA typical DC supply current while maintaining a regulated output voltage at no load.The LTC3630A can supply up to 500mA load current and features a programmable peak current limit that provides a simple method for optimizing efficiency and for reducing output ripple and component size. The LTC3630A’s combination of Burst Mode®operation, integrated power switches, low quiescent current, and programmable peak current limit provides high efficiency over a broad range of load currents.With its wide input range of 4V to 76V, the LTC3630A is a robust converter suited for regulating a wide variety of power sources. A feedback comparator output enables multiple LTC3630As to be paralleled in higher current applications.The LTC3630A is available in the thermally-enhanced 3mm × 5mm DFN and the MSE16 packages.Vin RangeLTC36304.5V to 65VLTC3630A4.5V to 76VAPPLICATIONSIndustrial Control SuppliesMedical DevicesPortable InstrumentsAutomotiveAvionics

The LTC3632 is a high efficiency, high voltage step-down DC/DC converter with internal high side and synchronous power switches that draws only 12μA typical DC supply current at no load while maintaining output voltage regulation.The LTC3632 can supply up to 20mA load current and features a programmable peak current limit that provides simple method for optimizing efficiency in lower current applications. The LTC3632’s combination of Burst Mode®operation, integrated power switches, low quiescent current, and programmable peak current limit provides high efficiency over a broad range of load currents.With its wide 4.5V to 50V input range and internal overvoltage monitor capable of protecting the part through 60V surges, the LTC3632 is a robust converter suited for regulating a wide variety of power sources. Additionally, the LTC3632 includes a precise run threshold and soft‑start feature to guarantee that the power system start-up is well-controlled in any environment.The LTC3632 is available in the thermally enhanced 3mm × 3mm DFN and MS8E packages.Applications4mA to 20mA Current LoopsIndustrial Control SuppliesDistributed Power SystemsPortable InstrumentsBattery-Operated DevicesAutomotive Power Systems

The LTC3633A-2 is a high efficiency, dual-channel monolithic synchronous buck regulator using a controlled on-time, current mode architecture, with phase lockable switching frequency. The two channels can run 180° out of phase to relax the requirements for input and output capacitance. The operating supply voltage range is from 3.6V to 20V, making it suitable for lithium-ion battery stacks as well as point of load power supply applications from a 12V or 5V supply.The operating frequency is programmable from 500kHz to 4MHz with an external resistor and may be synchronized to an external clock signal. The high frequency capability allows the use of small surface mount inductors and capacitors. The unique constant frequency/controlled on-time architecture is ideal for high step-down ratio applications that operate at high frequency while demanding fast transient response. An internal phase locked loop servos the on-time of the internal one-shot timer to match the frequency of the internal clock or an applied external clock.The LTC3633A-2 can select between forced continuous mode and high efficiency Burst Mode operation. The LTC3633A-2 and LTC3633A-3 differ in their output voltage sense range (refer to Table 1 in the Operation section of the datasheet for a description of the entire LTC3633A product family).Part NumberOutput Voltage Sense RangeSVin InputV2P5 OutputLTC3633 Pin CompatibleLTC3633A0.6V TO 6VNoYesYesLTC3633A-11.5V TO 12VNoYesYesLTC3633A-20.6V TO 6VYesNoNoLTC3633A-31.5V TO 12VYesNoNoApplicationsDistributed Power SystemsBattery Powered InstrumentsPoint of Load Power Supplies

The LTC3633A-2 is a high efficiency, dual-channel monolithic synchronous buck regulator using a controlled on-time, current mode architecture, with phase lockable switching frequency. The two channels can run 180° out of phase to relax the requirements for input and output capacitance. The operating supply voltage range is from 3.6V to 20V, making it suitable for lithium-ion battery stacks as well as point of load power supply applications from a 12V or 5V supply.The operating frequency is programmable from 500kHz to 4MHz with an external resistor and may be synchronized to an external clock signal. The high frequency capability allows the use of small surface mount inductors and capacitors. The unique constant frequency/controlled on-time architecture is ideal for high step-down ratio applications that operate at high frequency while demanding fast transient response. An internal phase locked loop servos the on-time of the internal one-shot timer to match the frequency of the internal clock or an applied external clock.The LTC3633A-2 can select between forced continuous mode and high efficiency Burst Mode operation. The LTC3633A-2 and LTC3633A-3 differ in their output voltage sense range (refer to Table 1 in the Operation section of the datasheet for a description of the entire LTC3633A product family).Part NumberOutput Voltage Sense RangeSVin InputV2P5 OutputLTC3633 Pin CompatibleLTC3633A0.6V TO 6VNoYesYesLTC3633A-11.5V TO 12VNoYesYesLTC3633A-20.6V TO 6VYesNoNoLTC3633A-31.5V TO 12VYesNoNoApplicationsDistributed Power SystemsBattery Powered InstrumentsPoint of Load Power Supplies

The LTC3633A is a high efficiency, dual-channel monolithic synchronous buck regulator using a controlled on-time, current mode architecture, with phase lockable switching frequency. The two channels can run 180° out of phase to relax the requirements for input and output capacitance. The operating supply voltage range is from 3.6V to 20V, making it suitable for lithium-ion battery stacks as well as point of load power supply applications from a 12V or 5V supply.The operating frequency is programmable from 500kHz to 4MHz with an external resistor and may be synchronized to an external clock signal. The high frequency capability allows the use of small surface mount inductors and capacitors. The unique constant frequency/controlled ontime architecture is ideal for high step-down ratio applications that operate at high frequency while demanding fast transient response. An internal phase locked loop servos the on-time of the internal one-shot timer to match the frequency of the internal clock or an applied external clock.The LTC3633A can select between forced continuous mode and high efficiency Burst Mode operation. The LTC3633A and LTC3633A-1 differ in their output voltage sense range (refer to Table 1 in the Operation section of the datasheet for a description of the entire LTC3633A product family).Part NumberOutput Voltage Sense RangeSVin InputV2P5 OutputLTC3633 Pin CompatibleLTC3633A0.6V TO 6VNoYesYesLTC3633A-11.5V TO 12VNoYesYesLTC3633A-20.6V TO 6VYesNoNoLTC3633A-31.5V TO 12VYesNoNoApplicationsDistributed Power SystemsBattery Powered InstrumentsPoint of Load Power Supplies
