MAX4526Phase-Reversal Analog Switches | Interface | 13 | Active | The MAX4526/MAX4527 are CMOS analog ICs configured as phase-reversal switches. The MAX4526 is optimized for high-speed applications, such as chopper amplifiers, while the MAX4527 is optimized for low-power applications.The MAX4526/MAX4527 operate from a +4.5V to +36V single supply or ±4.5V to ±18V dual supplies. On-resistance (175Ω max) is matched between switches to 8Ω maximum. Each switch can handle rail-to-rail analog signals. Maximum leakage current is only 0.5nA at +25°C and 10nA at +85°C.All digital inputs have 0.8V to 2.4V logic thresholds, ensuring TTL/CMOS-logic compatibility.ApplicationsAudio-Signal RoutingBalanced Modulators/DemodulatorsChopper-Stabilized AmplifiersData AcquisitionTest Equipment |
MAX4527Phase-Reversal Analog Switches | Interface | 13 | Active | The MAX4526/MAX4527 are CMOS analog ICs configured as phase-reversal switches. The MAX4526 is optimized for high-speed applications, such as chopper amplifiers, while the MAX4527 is optimized for low-power applications.The MAX4526/MAX4527 operate from a +4.5V to +36V single supply or ±4.5V to ±18V dual supplies. On-resistance (175Ω max) is matched between switches to 8Ω maximum. Each switch can handle rail-to-rail analog signals. Maximum leakage current is only 0.5nA at +25°C and 10nA at +85°C.All digital inputs have 0.8V to 2.4V logic thresholds, ensuring TTL/CMOS-logic compatibility.ApplicationsAudio-Signal RoutingBalanced Modulators/DemodulatorsChopper-Stabilized AmplifiersData AcquisitionTest Equipment |
| Integrated Circuits (ICs) | 16 | Active | |
MAX4529Low-Voltage, Bidirectional RF Video Switch | Integrated Circuits (ICs) | 10 | Active | The MAX4529 is a low-voltage T-switch designed for switching RF and video signals from DC to 300MHz in 50Ω and 75Ω systems. This switch is constructed in a "T" configuration, ensuring excellent high-frequency off isolation of -80dB at 10MHz.The MAX4529 can handle rail-to-rail analog signals in either direction. On-resistance (70Ω max) is flat (0.5Ω max) over the specified signal range, using ±5V supplies. The off leakage current is less than 1nA at +25°C and 20nA at +85°C.This CMOS switch can operate with dual power supplies ranging from ±2.7V to ±6V or a single supply between +2.7V and +12V. All digital inputs have 0.8V/2.4V logic thresholds, ensuring both TTL- and CMOS-logic compatibility when using ±5V or a single +5V supply.ApplicationsAutomated Test Equipment (ATE)High-Speed Data AcquisitionNetworkingRF SwitchingTest EquipmentVideo Signal Routing |
MAX453Quad, Low-Voltage, SPST Analog Switches with Enable | Uncategorized | 8 | Obsolete | Quad, Low-Voltage, SPST Analog Switches with Enable |
| Analog Switches, Multiplexers, Demultiplexers | 14 | Active | |
MAX4531Low-Voltage, CMOS Analog Multiplexers Switches with Enable Inputs and Address Latching | Integrated Circuits (ICs) | 8 | LTB | The MAX4530/MAX4531/MAX4532 are low-voltage, CMOS analog ICs configured as an 8-channel multiplexer (mux) (MAX4530), two 4-channel muxes (MAX4531), and three single-pole/double-throw switches (MAX4532). These devices are pin compatible with the industry-standard 74HC4351/74HC4352/74HC4353. All devices have two complementary switch-enable inputs and address latching.The MAX4530/MAX4531/MAX4532 operate from a single supply of +2V to +12V, or from dual supplies of ±2V to ±6V. On-resistance (150Ω max) is matched between switches to 8Ω max. Each switch can handle rail-to-rail analog signals. Off-leakage current is only 1nA at TA= +25°C and 50nA at TA= +85°C.All digital inputs have 0.8V and 2.4V logic thresholds, ensuring both TTL- and CMOS-logic compatibility when using ±5V or a single +5V supply.ApplicationsAudio-Signal RoutingAutomated Test Equipment (ATE)AvionicsBattery-Powered ApplicationsData AcquisitionNetworkingTest Equipment |
| Analog Switches, Multiplexers, Demultiplexers | 7 | LTB | |
MAX4533Quad, Rail-to-Rail, Fault-Protected, SPDT Analog Switch | Integrated Circuits (ICs) | 16 | Active | The MAX4533 quad, single-pole/double-throw (SPDT), fault-protected analog switch is pin-compatible with the industry-standard MAX333 and MAX333A. The MAX4533 features fault-protected inputs and rail-to-rail signal handling. The normally open (NO_ ) and normally closed (NC_ ) terminals are protected from overvoltage faults up to ±25V with power on and up to ±40V with power off. During a fault condition, NO_ and NC_ become high impedance with only nanoamperes of leakage current flowing to the source. In addition, the output (COM_) clamps to the appropriate polarity supply rail and provides up to ±10mA of load current. This ensures unambiguous rail-to-rail outputs when a fault occurs.The MAX4533 operates from dual ±4.5V to ±18V power supplies or a single +9V to +36V supply. All digital inputs have +0.8V and +2.4V logic thresholds, ensuring both TTL and CMOS logic compatibility when using ±15V supplies or a +12V supply. On-resistance is 175Ω max and is matched between switches to 10Ω max. The off-leakage current is only 0.5nA at TA= +25°C and 10nA at TA= +85°C.ApplicationsAvionics and Military SystemsCommunication SystemsData AcquisitionIndustrial and Process ControlPortable InstrumentationRedundant/Backup SystemsTest Equipment |
| Interface | 13 | Active | |
