396-011 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 11POS 0.125
| Part | Termination Rows | Material - Insulation | Gender | Number of Positions/Bay/Row | Number of Positions | Contact Type | Operating Temperature [Min] | Operating Temperature [Max] | Read Out | Mounting Type | Pitch | Pitch | Termination | Flange Feature [diameter] | Flange Feature [diameter] | Contact Finish Thickness | Contact Finish Thickness | Number of Rows | Card Type | Color | Contact Finish | Contact Material | Card Thickness [Max] | Card Thickness [Min] | Flange Feature | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyester Thermoplastic | Female | 11 | 11 | Cantilever | -40 C | 105 ░C | Single | Right Angle Through Hole | 3.18 mm | 0.125 in | Solder Wire Wrap | 0.156 " | 3.96 mm | 0.25 Ám | 10 Áin | 1 | Non Specified - Single Edge | Black | Gold | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | Female | 11 | 11 | Cantilever | -40 C | 105 ░C | Single | Through Hole | 3.18 mm | 0.125 in | Solder | 0.128 " | 3.25 mm | 0.25 Ám | 10 Áin | 1 | Non Specified - Single Edge | Black | Gold | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount Top Opening Unthreaded | |
 EDAC Inc. | 1 | Polyester Thermoplastic | Female | 11 | 11 | Cantilever | -40 C | 105 ░C | Single | Through Hole | 3.18 mm | 0.125 in | Solder | 0.25 Ám | 10 Áin | 1 | Non Specified - Single Edge | Black | Gold | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 4-40 Flush Mount Threaded Insert Top Opening | Card Guides | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | Female | 11 | 11 | Cantilever | -40 C | 105 ░C | Single | Through Hole | 3.18 mm | 0.125 in | Solder | 0.156 " | 3.96 mm | 0.25 Ám | 10 Áin | 1 | Non Specified - Single Edge | Black | Gold | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount Top Opening Unthreaded | |
 EDAC Inc. | 1 | Polyester Thermoplastic | Female | 11 | 11 | Cantilever | -40 C | 105 ░C | Single | Through Hole | 3.18 mm | 0.125 in | Wire Wrap | 0.116 " | 2.95 mm | 0.25 Ám | 10 Áin | 1 | Non Specified - Single Edge | Black | Gold | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Floating Bobbin Top Mount Opening | |
 EDAC Inc. | 1 | Polyester Thermoplastic | Female | 11 | 11 | Cantilever | -40 C | 105 ░C | Single | Right Angle Through Hole | 3.18 mm | 0.125 in | Solder Wire Wrap | 0.128 " | 3.25 mm | 0.25 Ám | 10 Áin | 1 | Non Specified - Single Edge | Black | Gold | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Side Mount Opening Unthreaded | |
 EDAC Inc. | 1 | Polyester Thermoplastic | Female | 11 | 11 | Cantilever | -40 C | 105 ░C | Single | Through Hole | 3.18 mm | 0.125 in | Solder | 0.25 Ám | 10 Áin | 1 | Non Specified - Single Edge | Black | Gold | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | M3 Threaded Insert Top Mount Opening | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | Female | 11 | 11 | Cantilever | -40 C | 105 ░C | Single | Through Hole | 3.18 mm | 0.125 in | Solder | 0.156 " | 3.96 mm | 0.25 Ám | 10 Áin | 1 | Non Specified - Single Edge | Black | Gold | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount Top Opening Unthreaded | |
 EDAC Inc. | 1 | Polyester Thermoplastic | Female | 11 | 11 | Cantilever | -40 C | 105 ░C | Single | Through Hole | 3.18 mm | 0.125 in | Wire Wrap | 0.25 Ám | 10 Áin | 1 | Non Specified - Single Edge | Black | Gold | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | M3 Threaded Insert Top Mount Opening | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | Female | 11 | 11 | Cantilever | -40 C | 105 ░C | Single | Right Angle Through Hole | 3.18 mm | 0.125 in | Solder Wire Wrap | 0.116 " | 2.95 mm | 0.25 Ám | 10 Áin | 1 | Non Specified - Single Edge | Black | Gold | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Floating Bobbin Flush Mount |
