629-11W Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN D-SUB PLUG 11POS R/A SLDR
| Part | Color | Operating Temperature [Min] | Operating Temperature [Max] | Voltage Rating | Dielectric Material | Contact Material | Number of Positions [custom] | Number of Positions [custom] | Connector Style | Current Rating (Amps) | Number of Rows [custom] | Backset Spacing | Backset Spacing | Mounting Type | Contact Type | Connector Type | Features | Contact Finish | Contact Finish Thickness | Contact Finish Thickness | Shell Material, Finish | Flange Feature | Termination | Shell Size, Connector Layout | Material Flammability Rating | Contact Finish Thickness | Flange Feature | Current Rating (Amps) | Number of Positions [custom] | Number of Positions [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Black | -55 C | 125 °C | 125 VDC | Polyester Thermoplastic | Copper Alloy | 10 | 1 | Combo D-Sub | 5 A 40 A | 2 | 9.4 mm | 0.37 in | Right Angle Through Hole | Signal and Power | Plug Male Pins | Board Lock Grounding Indents Mounting Brackets | Gold | 30 Áin | 0.76 Ám | Nickel Plated Steel | M3 | Solder | 2 (DA A) - 11C1 11W1 | UL94 V-0 | |||||
 EDAC Inc. | Black | -55 C | 125 °C | 125 VDC | Polyester Thermoplastic | Copper Alloy | 10 | 1 | Combo D-Sub | 5 A 40 A | 2 | 9.4 mm | 0.37 in | Right Angle Through Hole | Signal and Power | Plug Male Pins | Grounding Indents Mounting Brackets | Gold | 30 Áin | 0.76 Ám | Nickel Plated Steel | M3 | Solder | 2 (DA A) - 11C1 11W1 | UL94 V-0 | |||||
 EDAC Inc. | Black | -55 C | 125 °C | 125 VDC | Polyester Thermoplastic | Copper Alloy | 10 | 1 | Combo D-Sub | 5 A 40 A | 2 | 9.4 mm | 0.37 in | Right Angle Through Hole | Signal and Power | Plug Male Pins | Grounding Indents Mounting Brackets | Gold | Nickel Plated Steel | M3 | Solder | 2 (DA A) - 11C1 11W1 | UL94 V-0 | Flash | ||||||
 EDAC Inc. | Black | -55 C | 125 °C | 125 VDC | Polyester Thermoplastic | Copper Alloy | 10 | 1 | Combo D-Sub | 2 | 9.4 mm | 0.37 in | Right Angle Through Hole | Signal and Power | Plug Male Pins | Gold | Housing/Shell | Solder | 2 (DA A) - 11C1 11W1 | UL94 V-0 | Flash | 4-40 | 10A 5A | |||||||
 EDAC Inc. | Black | -55 C | 125 °C | 125 VDC | Polyester Thermoplastic | Copper Alloy | 10 | 1 | Combo D-Sub | 2 | 9.4 mm | 0.37 in | Right Angle Through Hole | Signal and Power | Plug Male Pins | Grounding Indents Mounting Brackets | Gold | 30 Áin | 0.76 Ám | Nickel Plated Steel | Housing/Shell | Solder | 2 (DA A) - 11C1 11W1 | UL94 V-0 | 4-40 | 20A 5A | ||||
 EDAC Inc. | Black | -55 C | 125 °C | 125 VDC | Polyester Thermoplastic | Copper Alloy | Combo D-Sub | 2 | 9.4 mm | 0.37 in | Right Angle Through Hole | Coax Signal | Plug Male Pins | Grounding Indents Shielded | Gold | 30 Áin | 0.76 Ám | Housing/Shell (Unthreaded) | Solder | 2 (DA A) - 11C1 11W1 | UL94 V-0 | 1 | 10 | |||||||
 EDAC Inc. | Black | -55 C | 125 °C | 125 VDC | Polyester Thermoplastic | Copper Alloy | 10 | 1 | Combo D-Sub | 5 A 30 A | 2 | 9.4 mm | 0.37 in | Right Angle Through Hole | Signal and Power | Plug Male Pins | Grounding Indents | Gold | Nickel Plated Steel | Board Side (M3) | Solder | 2 (DA A) - 11C1 11W1 | UL94 V-0 | Flash | ||||||
 EDAC Inc. | Black | -55 C | 125 °C | 125 VDC | Polyester Thermoplastic | Copper Alloy | 10 | 1 | Combo D-Sub | 2 | 9.4 mm | 0.37 in | Right Angle Through Hole | Signal and Power | Plug Male Pins | Gold | Housing/Shell | Solder | 2 (DA A) - 11C1 11W1 | UL94 V-0 | Flash | 4-40 | 20A 5A | |||||||
 EDAC Inc. | Black | -55 C | 125 °C | 125 VDC | Polyester Thermoplastic | Copper Alloy | Combo D-Sub | 2 | 9.4 mm | 0.37 in | Right Angle Through Hole | Coax Signal | Plug Male Pins | Gold | 30 Áin | 0.76 Ám | Housing/Shell | Solder | 2 (DA A) - 11C1 11W1 | UL94 V-0 | 4-40 | 1 | 10 | |||||||
 EDAC Inc. | Black | -55 C | 125 °C | 125 VDC | Polyester Thermoplastic | Copper Alloy | Combo D-Sub | 2 | 9.4 mm | 0.37 in | Right Angle Through Hole | Coax Signal | Plug Male Pins | Board Lock Grounding Indents Mounting Brackets | Gold | 30 Áin | 0.76 Ám | Housing/Shell (M3) | Solder | 2 (DA A) - 11C1 11W1 | UL94 V-0 | 1 | 10 |
