XS5G Series
Ethernet Cables / Networking Cables 5M Cable 2End Conn. M12 Right Angle Both
Manufacturer: Omron Automation and Safety
Catalog
Ethernet Cables / Networking Cables 5M Cable 2End Conn. M12 Right Angle Both
Beta
⌘K
Ethernet Cables / Networking Cables 5M Cable 2End Conn. M12 Right Angle Both
Ethernet Cables / Networking Cables 5M Cable 2End Conn. M12 Right Angle Both
Ethernet Cables / Networking Cables 5M Cable 2End Conn. M12 Right Angle Both
| Part | Orientation | Note | Housing Color | Number of Positions | Insert Material | Connector Type | Shell Material | Material Flammability Rating | Shell Finish | Operating Temperature [Min] | Operating Temperature [Max] | Fastening Type | Contact Type | Ingress Protection | Shielding | Contact Shape | Type | Shell Size - Insert | Mounting Type | Features | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Termination | Current Rating (Amps) | Contact Finish - Mating | Cable Opening [Max] | Cable Opening [Min] | Cable Opening [Min] | Cable Opening [Max] | Backshell Material, Plating | Primary Material | Color | Contact Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Omron Automation and Safety | Keyed | Contacts Not Included | Silver | 4 | Polybutylene Terephthalate Resin (PBT) | Plug Housing | Zinc Alloy | UL94 V-0 | Nickel | -25 °C | 70 °C | Bayonet Lock | Crimp | IP67 - Dust Tight Waterproof | Unshielded | Circular | For Male Pins | M12-4 | Free Hanging (In-Line) | Backshell | |||||||||||||
 Omron Automation and Safety | Keyed | 5 | Polybutylene Terephthalate (PBT) | Plug Male Pins | Zinc Alloy | UL94 V-0 | Nickel | -25 °C | 70 °C | Push-Twist | IP67 - Dust Tight Waterproof | M12-5 | Free Hanging (In-Line) | Backshell | 16 Áin | 0.41 Ám | Screw | 4 A | Gold | 0.197 in | 4 mm | 0.157 in | 5 mm | Polybutylene Terephthalate (PBT) | Metal | Black Silver | |||||||
Omron Automation and Safety | Keyed | 5 | Polybutylene Terephthalate (PBT) | Plug Male Pins | Zinc Alloy | UL94 V-0 | Nickel | -25 °C | 70 °C | Push-Twist | IP67 - Dust Tight Waterproof | M12-5 | Free Hanging (In-Line) | Backshell | 16 Áin | 0.41 Ám | Screw | 4 A | Gold | 0.236 in | 5 mm | 0.197 in | 6 mm | Polybutylene Terephthalate (PBT) | Metal | Black Silver | |||||||
 Omron Automation and Safety | Keyed | 4 | Polybutylene Terephthalate (PBT) | Plug Male Pins | Zinc Alloy | UL94 V-0 | Nickel | -25 °C | 70 °C | Push-Twist | IP67 - Dust Tight Waterproof | M12-4 | Free Hanging (In-Line) Right Angle | Backshell | 16 Áin | 0.41 Ám | 4 A | Gold | 0.157 in | 3 mm | 0.118 in | 4 mm | Polybutylene Terephthalate (PBT) | Metal | Black Silver | Brass | |||||||
 Omron Automation and Safety | Keyed | 4 | Polybutylene Terephthalate (PBT) | Plug Male Pins | Zinc Alloy | UL94 V-0 | Nickel | -25 °C | 70 °C | Push-Twist | IP67 - Dust Tight Waterproof | M12-4 | Free Hanging (In-Line) | Backshell | 16 Áin | 0.41 Ám | Screw | 4 A | Gold | 0.276 " | 6 mm | 0.236 in | 7 mm | Polybutylene Terephthalate (PBT) | Metal | Black Silver | |||||||
Omron Automation and Safety | Keyed | Contacts Not Included | Silver | 4 | Polybutylene Terephthalate Resin (PBT) | Plug Housing | Zinc Alloy | UL94 V-0 | Nickel | -25 °C | 70 °C | Bayonet Lock | Crimp | IP67 - Dust Tight Waterproof | Unshielded | Circular | For Male Pins | M12-4 | Free Hanging (In-Line) | Backshell | |||||||||||||
Omron Automation and Safety | Keyed | 4 | Polybutylene Terephthalate (PBT) | Plug Male Pins | Zinc Alloy | UL94 V-0 | Nickel | -25 °C | 70 °C | Push-Twist | IP67 - Dust Tight Waterproof | M12-4 | Free Hanging (In-Line) Right Angle | Backshell | 16 Áin | 0.41 Ám | 4 A | Gold | 0.197 in | 4 mm | 0.157 in | 5 mm | Polybutylene Terephthalate (PBT) | Metal | Black Silver | Brass | |||||||
 Omron Automation and Safety | Keyed | 4 | Polybutylene Terephthalate (PBT) | Plug Male Pins | Zinc Alloy | UL94 V-0 | Nickel | -25 °C | 70 °C | Push-Twist | IP67 - Dust Tight Waterproof | M12-4 | Free Hanging (In-Line) | Backshell | 16 Áin | 0.41 Ám | Solder | 4 A | Gold | 0.236 in | 5 mm | 0.197 in | 6 mm | Polybutylene Terephthalate (PBT) | Metal | Black Silver | Brass | ||||||
Omron Automation and Safety | Keyed | 4 | Polybutylene Terephthalate (PBT) | Plug Male Pins | Zinc Alloy | UL94 V-0 | Nickel | -25 °C | 70 °C | Push-Twist | IP67 - Dust Tight Waterproof | M12-4 | Free Hanging (In-Line) | Backshell | 16 Áin | 0.41 Ám | 4 A | Gold | 0.157 in | 3 mm | 0.118 in | 4 mm | Polybutylene Terephthalate (PBT) | Metal | Black Silver | Brass | |||||||
Omron Automation and Safety | Keyed | 5 | Polybutylene Terephthalate (PBT) | Plug Male Pins | Zinc Alloy | UL94 V-0 | Nickel | -25 °C | 70 °C | Push-Twist | IP67 - Dust Tight Waterproof | M12-5 | Free Hanging (In-Line) | Backshell | 16 Áin | 0.41 Ám | Screw | 4 A | Gold | 0.276 " | 6 mm | 0.236 in | 7 mm | Polybutylene Terephthalate (PBT) | Metal | Black Silver |
