3414.0114 Series
Manufacturer: SCHURTER Inc.
Beta
⌘K
FUSE BOARD MNT 750MA 32VDC 0402
| Part | DC Cold Resistance | Response Time | Breaking Capacity @ Rated Voltage | Current Rating (Amps) | Melting I²t | Fuse Type | Package / Case | Operating Temperature [Min] | Operating Temperature [Max] | Mounting Type | Voltage Rating - DC | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [z] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 SCHURTER Inc. | 0.078 Ohms | Fast Blow | 35 A | 750 mA | 0.009 | Board Mount (Cartridge Style Excluded) | 0402 (1005 Metric) | -55 C | 125 °C | Surface Mount | 32 V | 1 mm | 0.04 " | 0.48 mm | 0.02 in | 0.5 mm | 0.019 " |
