ATS-03E Series

Manufacturer: Advanced Thermal Solutions Inc.

Catalog

Catalog

HEAT SINKS PUSHPIN HEAT SINK ASSEMBLY, COARSE-PITCH/STRAIGHT, HOLE: LEFT-TAB, BLUE, NO TIM

...

Part	Attachment Method	Fin Height	Fin Height	Length [x]	Length [x]	Package Cooled	Thermal Resistance @ Forced Air Flow	Material	Type	Shape	Width	Width	Material Finish	Length	Width [x]	Width [x]	Fin Height [z]	Fin Height [z]	Fin Height [custom]	Fin Height [custom]	Length	Shape [custom]	Shape [custom]	Width [y]	Width [y]
Advanced Thermal Solutions Inc. ATS-03E-162-C1-R0	Push Pin	25 mm	0.984 in	1.772 in	45 mm	ASIC BGA CPU LGA	3.6 °C/W	Aluminum	Top Mount	Fins Square	1.772 in	45 mm	Blue Anodized
Advanced Thermal Solutions Inc. ATS-03E-45-C2-R0	Push Pin			0.984 in		ASIC BGA CPU LGA	15.02 °C/W	Aluminum	Top Mount	Fins Square			Blue Anodized	25 mm	25 mm	0.984 "	20 mm	0.79 in
Advanced Thermal Solutions Inc. ATS-03E-11-C3-R0	Push Pin			1.969 in	50 mm	ASIC BGA CPU LGA	18.86 °C/W	Aluminum	Top Mount	Fins Square			Blue Anodized		50 mm	1.969 in			0.394 "	10 mm
Advanced Thermal Solutions Inc. ATS-03E-41-C3-R0	Push Pin					ASIC BGA CPU LGA	10.07 °C/W	Aluminum	Top Mount				Blue Anodized	2.28 in					0.7 in	17.78 mm	57.9 mm	Rectangular	Fins	2.4 "	60.96 mm
Advanced Thermal Solutions Inc. ATS-03E-92-C3-R0	Push Pin					ASIC BGA CPU LGA	16.58 °C/W	Aluminum	Top Mount	Fins Square			Blue Anodized				15 mm	0.59 in						1.575 in	40 mm
Advanced Thermal Solutions Inc. ATS-03E-161-C2-R0	Push Pin			1.772 in	45 mm	ASIC BGA CPU LGA	4.74 °C/W	Aluminum	Top Mount	Fins Square	1.772 in	45 mm	Blue Anodized				20 mm	0.79 in
Advanced Thermal Solutions Inc. ATS-03E-118-C1-R0	Push Pin			1.772 in	45 mm	ASIC BGA CPU LGA	6.52 °C/W	Aluminum	Top Mount	Fins Square	1.772 in	45 mm	Blue Anodized				15 mm	0.59 in
Advanced Thermal Solutions Inc. ATS-03E-123-C2-R0	Push Pin			1.969 in	50 mm	ASIC BGA CPU LGA	4.16 °C/W	Aluminum	Top Mount	Fins Square			Blue Anodized		50 mm	1.969 in	20 mm	0.79 in
Advanced Thermal Solutions Inc. ATS-03E-194-C2-R0	Push Pin					ASIC BGA CPU LGA	13.07 °C/W	Aluminum	Top Mount	Fins Square			Blue Anodized						0.394 "	10 mm				1.575 in	40 mm
Advanced Thermal Solutions Inc. ATS-03E-123-C1-R0	Push Pin			1.969 in	50 mm	ASIC BGA CPU LGA	4.14 °C/W	Aluminum	Top Mount	Fins Square			Blue Anodized		50 mm	1.969 in	20 mm	0.79 in
