680S9W4 Series
Manufacturer: NorComp Inc.
Beta
⌘K
COMBINATION LAYOUT D SUB CONNECTOR, SEAL-D, IP68, SEAL-D 680S SERIES, DB-9W4, PLUG, 9 CONTACTS
| Part | Contact Material | Dielectric Material | Color | Operating Temperature [Max] | Operating Temperature [Min] | Contact Finish | Connector Type | Shell Material, Finish | Flange Feature | Mounting Type | Connector Style | Contact Finish Thickness | Number of Rows [custom] | Ingress Protection | Material Flammability Rating | Current Rating (Amps) | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [x] | Number of Positions [custom] | Number of Positions [custom] | Contact Type | Features | Current Rating (Amps) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NorComp Inc. | Copper Alloy | Polybutylene Terephthalate (PBT) | Black | 155 C | -55 C | Gold | Plug Male Pins | Nickel Plated Steel | Housing/Shell (Unthreaded) | Panel Mount | Combo D-Sub | Flash | 2 | IP67 - Dust Tight Waterproof | UL94 V-0 | 20A 5A | DB B - 9W4 | 3 | 4 | 5 | Signal and Power | Grounding Indents | |
 NorComp Inc. | Copper Alloy | Polybutylene Terephthalate (PBT) | Black | 155 C | -55 C | Gold | Plug Male Pins | Nickel Plated Steel | Housing/Shell (Unthreaded) | Panel Mount | Combo D-Sub | Flash | 2 | IP67 - Dust Tight Waterproof | UL94 V-0 | DB B - 9W4 | 3 | 4 | 5 | Signal and Power | Grounding Indents | 5 A 40 A |
