837-056 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 56POS 0.156
| Part | Material - Insulation | Termination Rows [custom] | Color | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Pitch | Pitch | Operating Temperature [Max] | Operating Temperature [Min] | Gender | Card Type | Contact Material | Number of Positions/Bay/Row | Card Thickness [Max] | Card Thickness [Min] | Contact Finish | Contact Finish Thickness | Contact Finish Thickness | Number of Rows [custom] | Read Out | Contact Type | Mounting Type | Number of Positions | Termination | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Green | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 3.96 mm | 0.156 in | 125 °C | -40 C | Female | Non Specified - Dual Edge | Copper Alloy | 28 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 0.25 Ám | 10 Áin | 2 | Dual | Cantilever | Through Hole | 56 | Solder Eyelet(s) | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Green | 3.25 mm | 0.128 " | 3.96 mm | 0.156 in | 125 °C | -40 C | Female | Non Specified - Dual Edge | Copper Alloy | 28 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 0.25 Ám | 10 Áin | 2 | Dual | Cantilever | Through Hole | 56 | Wire Wrap | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Green | Flush Mount M3 Threaded Insert Top Opening | 3.96 mm | 0.156 in | 125 °C | -40 C | Female | Non Specified - Dual Edge | Copper Alloy | 28 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 0.25 Ám | 10 Áin | 2 | Dual | Cantilever | Right Angle Through Hole | 56 | Solder | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Green | Floating Bobbin Flush Mount | 2.95 mm | 0.116 " | 3.96 mm | 0.156 in | 125 °C | -40 C | Female | Non Specified - Dual Edge | Copper Alloy | 28 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 0.25 Ám | 10 Áin | 2 | Dual | Cantilever | Through Hole | 56 | Wire Wrap | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Green | Side Mount Opening Unthreaded | 3.25 mm | 0.128 " | 3.96 mm | 0.156 in | 125 °C | -40 C | Female | Non Specified - Dual Edge | Copper Alloy | 28 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 0.25 Ám | 10 Áin | 2 | Dual | Cantilever | Right Angle Through Hole | 56 | Solder | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Green | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 3.96 mm | 0.156 in | 125 °C | -40 C | Female | Non Specified - Dual Edge | Copper Alloy | 28 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 0.25 Ám | 10 Áin | 2 | Dual | Cantilever | Board Edge Straddle Mount | 56 | Solder | Card Extender |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Green | M3 Threaded Insert Top Mount Opening | 3.96 mm | 0.156 in | 125 °C | -40 C | Female | Non Specified - Dual Edge | Copper Alloy | 28 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 0.25 Ám | 10 Áin | 2 | Dual | Cantilever | Through Hole | 56 | Wire Wrap | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Green | 3.96 mm | 0.156 " | 3.96 mm | 0.156 in | 125 °C | -40 C | Female | Non Specified - Dual Edge | Copper Alloy | 28 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 0.25 Ám | 10 Áin | 2 | Dual | Cantilever | Through Hole | 56 | Wire Wrap | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Green | 3.96 mm | 0.156 " | 3.96 mm | 0.156 in | 125 °C | -40 C | Female | Non Specified - Dual Edge | Copper Alloy | 28 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 0.25 Ám | 10 Áin | 2 | Dual | Cantilever | Right Angle Through Hole | 56 | Solder | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Green | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 " | 3.96 mm | 0.156 in | 125 °C | -40 C | Female | Non Specified - Dual Edge | Copper Alloy | 28 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 0.25 Ám | 10 Áin | 2 | Dual | Cantilever | Through Hole | 56 | Solder |
