ERJ-3BQFR Series

Catalog

RES 0.91 OHM 1% 1/4W 0603

Part	Tolerance	Package / Case	Ratings	Features	Number of Terminations	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Operating Temperature [Max]	Operating Temperature [Min]	Resistance	Power (Watts)	Power (Watts)	Temperature Coefficient [Max]	Composition	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]
Panasonic Industrial Automation Sales ERJ-3BQFR91V	1 %	0603 (1608 Metric)	AEC-Q200	Automotive AEC-Q200 Current Sense	2	0.8 mm	0.063 in	1.6 mm	0.031 in	155 °C	-55 °C	910 mOhms	0.25 W	250 mW	300 ppm/°C	Thick Film	0.022 in	0.55 mm
Panasonic Industrial Automation Sales ERJ-3BQFR39V	1 %	0603 (1608 Metric)	AEC-Q200	Automotive AEC-Q200 Current Sense	2	0.8 mm	0.063 in	1.6 mm	0.031 in	155 °C	-55 °C	390 mOhms	0.25 W	250 mW	300 ppm/°C	Thick Film	0.022 in	0.55 mm
Panasonic Industrial Automation Sales ERJ-3BQFR51V	1 %	0603 (1608 Metric)	AEC-Q200	Automotive AEC-Q200 Current Sense	2	0.8 mm	0.063 in	1.6 mm	0.031 in	155 °C	-55 °C	510 mOhms	0.25 W	250 mW	300 ppm/°C	Thick Film	0.022 in	0.55 mm
Panasonic Industrial Automation Sales ERJ-3BQFR47V	1 %	0603 (1608 Metric)	AEC-Q200	Automotive AEC-Q200 Current Sense	2	0.8 mm	0.063 in	1.6 mm	0.031 in	155 °C	-55 °C	470 mOhms	0.25 W	250 mW	300 ppm/°C	Thick Film	0.022 in	0.55 mm
Panasonic Industrial Automation Sales ERJ-3BQFR36V	1 %	0603 (1608 Metric)	AEC-Q200	Automotive AEC-Q200 Current Sense	2	0.8 mm	0.063 in	1.6 mm	0.031 in	155 °C	-55 °C	360 mOhms	0.25 W	250 mW	300 ppm/°C	Thick Film	0.022 in	0.55 mm
