9921 Series

Catalog

HOOK-UP STRND 22AWG BLACK

Part	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Jacket (Insulation) Material	Voltage	Ratings	Conductor Material	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Wire Gauge	Conductor Strand [custom]	Conductor Strand [custom]	Jacket Color	Operating Temperature [Min]	Operating Temperature [Max]	Cable Type	Length [x]	Length [x]	Length	Length
Belden Inc. 9921 0105000	0.41 mm	0.016 in	Poly-Vinyl Chloride (PVC)	300 VDC	UL Style 1007/1569	Copper Tinned	0.062 in	1.57 mm	22 AWG	30 AWG	7	Black	-20 ░C	105 ░C	Hook-Up
Belden Inc. 9921 007100	0.41 mm	0.016 in	Poly-Vinyl Chloride (PVC)	300 VDC	UL Style 1007/1569	Copper Tinned	0.062 in	1.57 mm	22 AWG	30 AWG	7	Violet	-20 ░C	105 ░C	Hook-Up	100 ft	30.5 m
Belden Inc. 9921 013100	0.41 mm	0.016 in	Poly-Vinyl Chloride (PVC)	300 VDC	UL Style 1007/1569	Copper Tinned	0.062 in	1.57 mm	22 AWG	30 AWG	7	Blue	-20 ░C	105 ░C	Hook-Up	100 ft	30.5 m
Belden Inc. 9921 0051000	0.41 mm	0.016 in	Poly-Vinyl Chloride (PVC)	300 VDC	UL Style 1007/1569	Copper Tinned	0.062 in	1.57 mm	22 AWG	30 AWG	7	Green	-20 ░C	105 ░C	Hook-Up			304.8 m	1000 ft
Belden Inc. 9921 0025000	0.41 mm	0.016 in	Poly-Vinyl Chloride (PVC)	300 VDC	UL Style 1007/1569	Copper Tinned	0.062 in	1.57 mm	22 AWG	30 AWG	7	Red	-20 ░C	105 ░C	Hook-Up
Belden Inc. 9921 0071000	0.41 mm	0.016 in	Poly-Vinyl Chloride (PVC)	300 VDC	UL Style 1007/1569	Copper Tinned	0.062 in	1.57 mm	22 AWG	30 AWG	7	Violet	-20 ░C	105 ░C	Hook-Up			304.8 m	1000 ft
Belden Inc. 9921 010100	0.41 mm	0.016 in	Poly-Vinyl Chloride (PVC)	300 VDC	UL Style 1007/1569	Copper Tinned	0.062 in	1.57 mm	22 AWG	30 AWG	7	Black	-20 ░C	105 ░C	Hook-Up	100 ft	30.5 m
Belden Inc. 9921 0135000	0.41 mm	0.016 in	Poly-Vinyl Chloride (PVC)	300 VDC	UL Style 1007/1569	Copper Tinned	0.062 in	1.57 mm	22 AWG	30 AWG	7	Blue	-20 ░C	105 ░C	Hook-Up
Belden Inc. 9921 004100	0.41 mm	0.016 in	Poly-Vinyl Chloride (PVC)	300 VDC	UL Style 1007/1569	Copper Tinned	0.062 in	1.57 mm	22 AWG	30 AWG	7	Yellow	-20 ░C	105 ░C	Hook-Up	100 ft	30.5 m
Belden Inc. 9921 002100	0.41 mm	0.016 in	Poly-Vinyl Chloride (PVC)	300 VDC	UL Style 1007/1569	Copper Tinned	0.062 in	1.57 mm	22 AWG	30 AWG	7	Red	-20 ░C	105 ░C	Hook-Up	100 ft	30.5 m
