306-025 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CARD EDGE CONNECTOR, SINGLE SIDE, 1.57 MM, 25 CONTACTS, PANEL MOUNT, STRAIGHT
| Part | Material - Insulation | Termination Rows | Pitch | Pitch | Flange Feature | Gender | Operating Temperature [Min] | Operating Temperature [Max] | Contact Finish | Number of Positions | Color | Number of Rows [custom] | Card Type | Termination | Mounting Type | Contact Type | Number of Positions/Bay/Row | Read Out | Contact Material | Card Thickness [Max] | Card Thickness [Min] | Contact Finish Thickness | Contact Finish Thickness | Flange Feature [diameter] | Flange Feature [diameter] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 1 | 3.96 mm | 0.156 in | 4-40 Flush Mount Threaded Insert Top Opening | Female | -40 C | 105 ░C | Tin | 50 | Green | 2 | Non Specified - Dual Edge | Solder Eyelet(s) | Panel Mount | Cantilever | 25 | Dual | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | |||||
 EDAC Inc. | Polyester Thermoplastic | 1 | 3.96 mm | 0.156 in | Female | -40 C | 105 ░C | Gold | 50 | Green | 2 | Non Specified - Dual Edge | Solder Eyelet(s) | Free Hanging (In-Line) | Cantilever | 25 | Dual | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | ||||
 EDAC Inc. | Polyester Thermoplastic | 1 | 3.96 mm | 0.156 in | Flush Mount Side Opening Unthreaded | Female | -40 C | 105 ░C | Gold | 50 | Green | 2 | Non Specified - Dual Edge | Solder Eyelet(s) | Panel Mount | Cantilever | 25 | Dual | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 0.128 " | 3.25 mm | |
 EDAC Inc. | Polyester Thermoplastic | 1 | 3.96 mm | 0.156 in | 4-40 Flush Mount Threaded Insert Top Opening | Female | -40 C | 105 ░C | Tin | 50 | Green | 2 | Non Specified - Dual Edge | Solder | Panel Mount Through Hole | Cantilever | 25 | Dual | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Card Guides | ||||
 EDAC Inc. | Polyester Thermoplastic | 1 | 3.96 mm | 0.156 in | Flush Mount Side Opening Unthreaded | Female | -40 C | 105 ░C | Gold | 50 | Green | 2 | Non Specified - Dual Edge | Solder | Panel Mount Through Hole | Cantilever | 25 | Dual | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 0.128 " | 3.25 mm | |
 EDAC Inc. | Polyester Thermoplastic | 1 | 3.96 mm | 0.156 in | Flush Mount Top Opening Unthreaded | Female | -40 C | 105 ░C | Tin | 50 | Green | 2 | Non Specified - Dual Edge | Solder Eyelet(s) | Panel Mount | Cantilever | 25 | Dual | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.128 " | 3.25 mm | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | 3.96 mm | 0.156 in | Flush Mount Top Opening Unthreaded | Female | -40 C | 105 ░C | Tin | 50 | Green | 2 | Non Specified - Dual Edge | Solder Eyelet(s) | Panel Mount | Cantilever | 25 | Dual | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.156 " | 3.96 mm | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | 3.96 mm | 0.156 in | 4-40 Flush Mount Threaded Insert Top Opening | Female | -40 C | 105 ░C | Tin | 50 | Green | 2 | Non Specified - Dual Edge | Solder | Panel Mount Through Hole | Cantilever | 25 | Dual | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Card Guides | ||||
 EDAC Inc. | Polyester Thermoplastic | 1 | 3.96 mm | 0.156 in | Female | -40 C | 105 ░C | Tin | 50 | Green | 2 | Non Specified - Dual Edge | Solder | Through Hole | Cantilever | 25 | Dual | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | ||||||
 EDAC Inc. | Polyester Thermoplastic | 1 | 3.96 mm | 0.156 in | Female | -40 C | 105 ░C | Gold | 50 | Green | 2 | Non Specified - Dual Edge | Solder | Through Hole | Cantilever | 25 | Dual | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin |
