091813 Series

Manufacturer: Molex

Catalog

CONN RCPT HSG 9POS 5.08MM

Part	Contact Termination	Contact Type	Mounting Type	Color	Number of Positions	Number of Rows	Insulation Material	Connector Type	Note	Fastening Type	Pitch [x]	Pitch [x]	Operating Temperature [Min]	Operating Temperature [Max]
Molex 0918139109	Crimp	Non-Gendered	Free Hanging (In-Line)	White	9	1	Polyamide (PA6) Nylon 6	Receptacle	Contacts Not Included	Locking Ramp	0.2 in	5.08 mm
Molex 0918139010	Crimp	Non-Gendered	Free Hanging (In-Line)	White	10	1	Polyamide (PA6) Nylon 6	Receptacle	Contacts Not Included		0.2 in	5.08 mm
Molex 0918139006	Crimp	Non-Gendered	Free Hanging (In-Line)	White	6	1	Polyamide (PA6) Nylon 6	Receptacle	Contacts Not Included		0.2 in	5.08 mm	-40 °C	105 ░C
Molex 0918139103	Crimp	Non-Gendered	Free Hanging (In-Line)	White		1	Polyamide (PA6) Nylon 6	Receptacle	Contacts Not Included	Locking Ramp	0.2 in	5.08 mm
Molex 0918139012	Crimp	Non-Gendered	Free Hanging (In-Line)	White	12	1	Polyamide (PA6) Nylon 6	Receptacle	Contacts Not Included		0.2 in	5.08 mm
Molex 0918139108	Crimp	Non-Gendered	Free Hanging (In-Line)	White	8	1	Polyamide (PA6) Nylon 6	Receptacle	Contacts Not Included	Locking Ramp	0.2 in	5.08 mm	-40 °C	105 ░C
Molex 0918139003	Crimp	Non-Gendered	Free Hanging (In-Line)	White		1	Polyamide (PA6) Nylon 6	Receptacle	Contacts Not Included		0.2 in	5.08 mm
Molex 0918139009	Crimp	Non-Gendered	Free Hanging (In-Line)	White	9	1	Polyamide (PA6) Nylon 6	Receptacle	Contacts Not Included		0.2 in	5.08 mm	-40 °C	105 ░C
Molex 0918139102	Crimp	Non-Gendered	Free Hanging (In-Line)	White	2	1	Polyamide (PA6) Nylon 6	Receptacle	Contacts Not Included	Locking Ramp	0.2 in	5.08 mm
Molex 0918139004	Crimp	Non-Gendered	Free Hanging (In-Line)	White	4	1	Polyamide (PA6) Nylon 6	Receptacle	Contacts Not Included		0.2 in	5.08 mm
