LB25RKW01 Series

Catalog

STANDARD SIZE PANEL SEAL PUSHBUTTON

Part	Mechanical Life	Electrical Life	Color - Actuator/Cap	Illumination Voltage (Nominal)	Panel Cutout Dimensions [y]	Panel Cutout Dimensions [x]	Circuit	Type	Actuator Type	Mounting Type	Switch Function	Termination Style	Voltage Rating - DC	Actuator Marking	Current Rating (Amps)	Illumination Type, Color	Operating Temperature [Max]	Operating Temperature [Min]	Voltage Rating - AC
NKK Switches LB25RKW01-5C-JC	1000000 Cycles	100000 Cycles	Clear	1.9 VDC	16.2 mm	22.4 mm	DPDT	Illuminated Standard	Button Rectangular	Panel Mount Snap-In	On-Mom	Solder Quick Connect - 0.110" (2.8mm)	30 V	No Marking	3 A	LED Red	50 °C	-25 °C	125 V
NKK Switches LB25RKW01-5D12-JB	1000000 Cycles	100000 Cycles	Clear	12 VDC	16.2 mm	22.4 mm	DPDT	Illuminated Standard	Button Rectangular	Panel Mount Snap-In	On-Mom	Solder Quick Connect - 0.110" (2.8mm)	30 V	No Marking	3 A	Amber LED	50 °C	-25 °C	125 V
NKK Switches LB25RKW01-5C12-JC	1000000 Cycles	100000 Cycles	Clear	12 VDC	16.2 mm	22.4 mm	DPDT	Illuminated Standard	Button Rectangular	Panel Mount Snap-In	On-Mom	Solder Quick Connect - 0.110" (2.8mm)	30 V	No Marking	3 A	LED Red	50 °C	-25 °C	125 V
NKK Switches LB25RKW01-5D24-JD	1000000 Cycles	100000 Cycles	Clear	24 V	16.2 mm	22.4 mm	DPDT	Illuminated Standard	Button Rectangular	Panel Mount Snap-In	On-Mom	Solder Quick Connect - 0.110" (2.8mm)	30 V	No Marking	3 A	Amber LED	50 °C	-25 °C	125 V
NKK Switches LB25RKW01-5F24-JF	1000000 Cycles	100000 Cycles	Clear	24 V	16.2 mm	22.4 mm	DPDT	Illuminated Standard	Button Rectangular	Panel Mount Snap-In	On-Mom	Solder Quick Connect - 0.110" (2.8mm)	30 V	No Marking	3 A	Green LED	50 °C	-25 °C	125 V
NKK Switches LB25RKW01-5F12-JF	1000000 Cycles	100000 Cycles	Clear	12 VDC	16.2 mm	22.4 mm	DPDT	Illuminated Standard	Button Rectangular	Panel Mount Snap-In	On-Mom	Solder Quick Connect - 0.110" (2.8mm)	30 V	No Marking	3 A	Green LED	50 °C	-25 °C	125 V
NKK Switches LB25RKW01-5C24-JB	1000000 Cycles	100000 Cycles	Clear	24 V	16.2 mm	22.4 mm	DPDT	Illuminated Standard	Button Rectangular	Panel Mount Snap-In	On-Mom	Solder Quick Connect - 0.110" (2.8mm)	30 V	No Marking	3 A	LED Red	50 °C	-25 °C	125 V
NKK Switches LB25RKW01-5D05-JD	1000000 Cycles	100000 Cycles	Clear	5 VDC	16.2 mm	22.4 mm	DPDT	Illuminated Standard	Button Rectangular	Panel Mount Snap-In	On-Mom	Solder Quick Connect - 0.110" (2.8mm)	30 V	No Marking	3 A	Amber LED	50 °C	-25 °C	125 V
NKK Switches LB25RKW01-5C05-JC	1000000 Cycles	100000 Cycles	Clear	5 VDC	16.2 mm	22.4 mm	DPDT	Illuminated Standard	Button Rectangular	Panel Mount Snap-In	On-Mom	Solder Quick Connect - 0.110" (2.8mm)	30 V	No Marking	3 A	LED Red	50 °C	-25 °C	125 V
NKK Switches LB25RKW01-5F05-JF	1000000 Cycles	100000 Cycles	Clear	5 VDC	16.2 mm	22.4 mm	DPDT	Illuminated Standard	Button Rectangular	Panel Mount Snap-In	On-Mom	Solder Quick Connect - 0.110" (2.8mm)	30 V	No Marking	3 A	Green LED	50 °C	-25 °C	125 V
