BFN0724 Series
Manufacturer: Delta Electronics
Beta
⌘K
FAN BLOWER 57.5MM 24VDC
| Part | Material - Frame | Current Rating (Amps) | Material - Blade | Lifetime @ Temp. | Weight [custom] | Weight [custom] | Approval Agency | Voltage - Rated | RPM | Noise | Width [y] | Operating Temperature [Min] | Operating Temperature [Max] | Static Pressure | Static Pressure | Fan Type | Bearing Type | Power (Watts) | Termination | Air Flow | Air Flow | Ingress Protection |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Delta Electronics | Plastic | 1.5 A | Plastic | 15000 Hrs | 230.42 g | 0.508 lb | CE | 24 VDC | 17300 RPM | 38 dB(A) | 57.5 mm | -10 °C | 40 °C | 19.66 in H2O | 4897.1 Pa | Blower | Ball | 36 W | 3 Position Rectangular Connector 6 Position Rectangular Connector | 18.1 CFM | 0.507 mł/min | IP20 |
