SFV4R Series
Manufacturer: Amphenol ICC (FCI)
Beta
⌘K
CONN FFC BOTTOM 4POS 0.5MM R/A
| Part | Actuator Color | Mating Cycles | Housing Color | Current Rating (Amps) | Contact Finish | Locking Feature | Mounting Type | Number of Positions | Cable End Type | Height Above Board [z] | Height Above Board [z] | Pitch | Pitch | Connector/Contact Type | Operating Temperature [Min] | Operating Temperature [Max] | Housing Material | Material Flammability Rating | Termination | Flat Flex Type | Voltage Rating | FFC, FCB Thickness | Actuator Material | Contact Material | Features | FFC, FCB Thickness [custom] | FFC, FCB Thickness [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Amphenol ICC (FCI) | Black | 20 | Black | 0.5 A | Tin | Slide Lock | Right Angle Surface Mount | 4 | Straight | 0.071 in | 1.8 mm | 0.02 " | 0.5 mm | Contacts Bottom | -55 C | 105 ░C | Glass Filled Halogen Free Nylon Polyamide (PA) | UL94 V-0 | Solder | FFC FPC | 50 V | 0.3 mm | Polyphenylene Sulfide (PPS) Glass Filled Halogen Free | Phosphor Bronze | Solder Retention Zero Insertion Force (ZIF) | ||
 Amphenol ICC (FCI) | Black | 20 | Black | 0.5 A | Gold | Slide Lock | Right Angle Surface Mount | 4 | Straight Tapered | 0.071 in | 1.8 mm | 0.02 " | 0.5 mm | Contacts Top | -55 C | 105 ░C | Glass Filled Halogen Free Nylon Polyamide (PA) | UL94 V-0 | Solder | FFC FPC | 50 V | Polyphenylene Sulfide (PPS) Glass Filled Halogen Free | Phosphor Bronze | 0.3 mm | 0.33 mm | ||
 Amphenol ICC (FCI) | Brown | 20 | Black | 0.5 A | Tin | Slide Lock | Right Angle Surface Mount | 4 | Notched | 0.071 in | 1.8 mm | 0.02 " | 0.5 mm | Contacts Top | -55 C | 105 ░C | Glass Filled Halogen Free Nylon Polyamide (PA) | UL94 V-0 | Solder | FFC FPC | 50 V | Polyphenylene Sulfide (PPS) Glass Filled Halogen Free | Phosphor Bronze | 0.3 mm | 0.33 mm | ||
 Amphenol ICC (FCI) | Slide Lock | Right Angle Surface Mount | 4 | 0.02 " | 0.5 mm | Contacts Top | Solder | ||||||||||||||||||||
 Amphenol ICC (FCI) | Brown | 20 | Black | 0.5 A | Gold | Slide Lock | Right Angle Surface Mount | 4 | Notched | 0.071 in | 1.8 mm | 0.02 " | 0.5 mm | Contacts Top | -55 C | 105 ░C | Glass Filled Halogen Free Nylon Polyamide (PA) | UL94 V-0 | Solder | FPC | 50 V | Polyphenylene Sulfide (PPS) Glass Filled Halogen Free | Phosphor Bronze | 0.3 mm | 0.33 mm | ||
Amphenol ICC (FCI) | Beige | 20 | Black | 0.5 A | Gold | Slide Lock | Right Angle Surface Mount | 4 | Tapered | 0.071 in | 1.8 mm | 0.02 " | 0.5 mm | Contacts Bottom | -55 C | 105 ░C | Glass Filled Halogen Free Nylon Polyamide (PA) | UL94 V-0 | Solder | FPC | 50 V | 0.3 mm | Polyphenylene Sulfide (PPS) Glass Filled Halogen Free | Phosphor Bronze | |||
 Amphenol ICC (FCI) | Brown | Black | 0.5 A | Tin | Slide Lock | Right Angle Surface Mount | 4 | Straight Tapered | 0.071 in | 1.8 mm | 0.02 " | 0.5 mm | Contacts Bottom | -55 C | 105 ░C | Glass Filled Nylon Polyamide (PA) | UL94 V-0 | Solder | FFC FPC | 50 V | Polyphenylene Sulfide (PPS) Glass Filled | Phosphor Bronze | Solder Retention Zero Insertion Force (ZIF) | 0.3 mm | 0.33 mm | ||
Amphenol ICC (FCI) |
