5201FE Series
Manufacturer: Belden Inc.
Beta
⌘K
CABLE 3CON 16AWG GRAY SHLD
| Part | Shield Material | Shield Coverage | Jacket Color | Shield Type | Jacket (Insulation) Material | Length | Length | Conductor Insulation | Ratings | Conductor Material | Features | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Usage | Conductor Strand [custom] | Conductor Strand [custom] | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Cable Type | Number of Conductors | Voltage | Wire Gauge |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Belden Inc. | Aluminum | 100 % | Gray | Foil | Poly-Vinyl Chloride (PVC) Riser | 304.8 m | 1000 ft | Polypropylene (PP) | UL Style CMR | Copper Bare | Drain Wire Rip Cord | 0.195 " | 4.95 mm | Security Sound | 19 | 29 | 0.017 " | 0.432 mm | Multi-Conductor | 3 | 300 VDC | 16 AWG |
 Belden Inc. | Aluminum | 100 % | Gray | Foil | Poly-Vinyl Chloride (PVC) Riser | 304.8 m | 1000 ft | Polypropylene (PP) | UL Style CMR | Copper Bare | Drain Wire Rip Cord | 0.195 " | 4.95 mm | Security Sound | 19 | 29 | 0.017 " | 0.432 mm | Multi-Conductor | 3 | 300 VDC | 16 AWG |
Belden Inc. | Aluminum | 100 % | Gray | Foil | Poly-Vinyl Chloride (PVC) Riser | 152.4 m | 500 ft | Polypropylene (PP) | UL Style CMR | Copper Bare | Drain Wire Rip Cord | 0.195 " | 4.95 mm | Security Sound | 19 | 29 | 0.017 " | 0.432 mm | Multi-Conductor | 3 | 300 VDC | 16 AWG |
