CAR2024 Series
Manufacturer: OmniOn Power™
Beta
⌘K
AC/DC CONVERTER 24V 2000W
| Part | Features | Operating Temperature [Max] | Operating Temperature [Min] | Mounting Type | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Voltage - Isolation | Type | Number of Outputs | Minimum Load Required | Applications | Efficiency | Voltage - Output 1 | Current - Output 1 | Power (Watts) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 OmniOn Power™ | Adjustable Output Hot Swappable I2C Interface Load Sharing PFC PMBus™ Remote Sense Standby Output Universal Input | 70 °C | -10 °C | Rack Mount | 14.25 " | 1.65 " | 41.9 mm | 4 " | 101.6 mm | 362 mm | 3000 V | Front End | 1 | ITE (Commercial) | 90 % | 24 V | 83 A | 2 kW | |
OmniOn Power™ | Adjustable Output Hot Swappable I2C Interface Load Sharing PFC PMBus™ Remote Sense Standby Output Universal Input | 70 °C | -10 °C | Rack Mount | 14.25 " | 1.65 " | 41.9 mm | 4 " | 101.6 mm | 362 mm | 3000 V | Front End | 1 | ITE (Commercial) | 90 % | 24 V | 83 A | 2 kW |
