SRF0703 Series
Manufacturer: Bourns Inc.
Beta
⌘K
INDUCTOR, POWER, 1.5 µH, 20%, 0.0191 OHM, 4.64 A, 7.6MM X 7.6MM X 3.4MM
| Part | Tolerance | Operating Temperature [Max] | Operating Temperature [Min] | Inductance - Connected In Parallel | Height | Height | Current Rating - Series | DC Resistance (DCR) - Parallel | Current Saturation - Series | Current Saturation - Parallel | Current Rating - Parallel | Number of Coils | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] | DC Resistance (DCR) - Series [Max] | Package / Case | Mounting Type | Inductance - Connected In Series | Shielding | DC Resistance (DCR) - Series | DC Resistance (DCR) - Parallel [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Bourns Inc. | 20 % | 125 °C | -40 C | 1.5 µH | 0.142 in | 3.6 mm | 2.32 A | 19.1 mOhm | 3.26 A | 6.52 A | 4.64 A | 2 | 0.299 " | 7.6 mm | 7.6 mm | 0.299 " | 110 mOhm | Nonstandard | Surface Mount | 6 µH | Shielded | ||
Bourns Inc. | 20 % | 125 °C | -40 C | 3.3 µH | 0.142 in | 3.6 mm | 31.6 mOhm | 2.11 A | 4.22 A | 3.31 A | 2 | 0.299 " | 7.6 mm | 7.6 mm | 0.299 " | Nonstandard | Surface Mount | 13.2 µH | Shielded | 182 mOhm | |||
Bourns Inc. | 20 % | 125 °C | -40 C | 150 µH | 0.142 in | 3.6 mm | 289 mA | 986 mOhm | 320 mA | 650 mA | 580 mA | 2 | 0.299 " | 7.6 mm | 7.6 mm | 0.299 " | Nonstandard | Surface Mount | 600 µH | Shielded | 3.63 Ohm | ||
 Bourns Inc. | 20 % | 125 °C | -40 C | 0.142 in | 3.6 mm | 811 mA | 830 mA | 1.67 A | 1.62 A | 2 | 0.299 " | 7.6 mm | 7.6 mm | 0.299 " | 620 mOhm | Nonstandard | Surface Mount | 88 µH | Shielded | 150 mOhm | |||
 Bourns Inc. | 20 % | 125 °C | -40 C | 100 µH | 0.142 in | 3.6 mm | 367 mA | 715 mOhm | 390 mA | 790 mA | 730 mA | 2 | 0.299 " | 7.6 mm | 7.6 mm | 0.299 " | Nonstandard | Surface Mount | 400 µH | Shielded | 2.64 Ohm | ||
 Bourns Inc. | 20 % | 125 °C | -40 C | 470 µH | 0.142 in | 3.6 mm | 173 mA | 180 mA | 370 mA | 350 mA | 2 | 0.299 " | 7.6 mm | 7.6 mm | 0.299 " | Nonstandard | Surface Mount | 1.88 mH | Shielded | 11.22 Ohm | 2.82 Ohm | ||
Bourns Inc. | 20 % | 125 °C | -40 C | 33 µH | 0.142 in | 3.6 mm | 653 mA | 240 mOhm | 680 mA | 1.35 A | 1.31 A | 2 | 0.299 " | 7.6 mm | 7.6 mm | 0.299 " | Nonstandard | Surface Mount | 132 µH | Shielded | 1 Ohm | ||
Bourns Inc. | 20 % | 125 °C | -40 C | 15 µH | 0.142 in | 3.6 mm | 916 mA | 119 mOhm | 1.03 A | 2.05 A | 1.83 A | 2 | 0.299 " | 7.6 mm | 7.6 mm | 0.299 " | 470 mOhm | Nonstandard | Surface Mount | 60 µH | Shielded | ||
Bourns Inc. | 20 % | 125 °C | -40 C | 47 µH | 0.142 in | 3.6 mm | 542 mA | 570 mA | 1.08 A | 2 | 0.299 " | 7.6 mm | 7.6 mm | 0.299 " | 1.28 Ohm | Nonstandard | Surface Mount | 188 µH | Shielded | 338 mOhm |
