3118-2 Series
Manufacturer: Mill-Max Manufacturing Corp.
Beta
⌘K
CONN PC PIN CIRC 0.025DIA GOLD
| Part | Length - Overall [x] | Length - Overall [x] | Insulation | Board Thickness | Board Thickness | Length - Above Flange | Length - Above Flange [x] | Terminal Style | Length - Below Flange [x] | Length - Below Flange [x] | Flange Diameter | Flange Diameter | Mounting Hole Diameter [diameter] | Mounting Hole Diameter [diameter] | Pin Size - Above Flange [diameter] | Pin Size - Above Flange [diameter] | Contact Finish Thickness | Contact Finish Thickness | Contact Finish | Contact Material | Mounting Type | Termination | Terminal Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Mill-Max Manufacturing Corp. | 0.402 " | 10.2 mm | Non-Insulated | 1.57 mm | 0.062 " | 3.81 mm | 0.15 in | Single End | 2.08 mm | 0.082 " | 0.05 in | 1.27 mm | 0.89 mm | 0.035 in | 0.64 mm | 0.025 in | 20 µin | 0.51 µm | Gold | Brass Alloy | Through Hole | Swage | PC Pin |
 Mill-Max Manufacturing Corp. | 0.402 " | 10.2 mm | Non-Insulated | 1.57 mm | 0.062 " | 3.81 mm | 0.15 in | Single End | 2.08 mm | 0.082 " | 0.05 in | 1.27 mm | 0.89 mm | 0.035 in | 0.64 mm | 0.025 in | 50 µin | 1.27 µm | Gold | Brass Alloy | Through Hole | Swage | PC Pin |
 Mill-Max Manufacturing Corp. | 0.402 " | 10.2 mm | Non-Insulated | 1.57 mm | 0.062 " | 3.81 mm | 0.15 in | Single End | 2.08 mm | 0.082 " | 0.05 in | 1.27 mm | 0.89 mm | 0.035 in | 0.64 mm | 0.025 in | 200 Áin | 5.08 Ám | Tin | Brass Alloy | Through Hole | Swage | PC Pin |
