UF12B Series

Catalog

FAN AXIAL 120X38MM 115VAC WIRE

Part	Material - Blade	Lifetime @ Temp.	Current Rating (Amps)	Material - Frame	Fan Type	Size / Dimension [z]	Size / Dimension [x]	Power (Watts)	Bearing Type	Noise	Voltage - Rated	Static Pressure	Static Pressure	Operating Temperature [Min]	Operating Temperature [Max]	Operating Temperature [Max]	Operating Temperature [Min]	RPM	Termination	Air Flow	Air Flow	Approval Agency	Weight	Weight	Width [y]	Termination	Features
Mechatronics Fan Group UF12B12-BWLR	Polybutylene Terephthalate (PBT)	50000 Hrs	110 mA	Aluminum	Tubeaxial	120 mm	120 mm	11 W	Ball	33 dB(A)	115 VAC	0.11 in H2O	27.4 Pa	-40 C	70 °C	70 °C	-40 °C	2000 RPM	2 Wire Leads	53 CFM	1.48 mł/min	CE cUL TUV UL	0.725 lb	328.85 g	25 mm
Mechatronics Fan Group UF12B23-BTHR	Polybutylene Terephthalate (PBT)	50000 Hrs	70 mA	Aluminum	Tubeaxial	120 mm	120 mm	14 W	Ball	42 dB	230 VAC	0.24 in H2O	59.8 Pa	-40 C	70 °C	70 °C	-40 °C	2900 RPM		75 CFM	2.1 m³/min	CE cUL TUV UL	0.725 lb	328.85 g	25 mm	2
Mechatronics Fan Group UF12B23-BTLR	Polybutylene Terephthalate (PBT)	50000 Hrs	60 mA	Aluminum	Tubeaxial	120 mm	120 mm	14 W	Ball	33 dB(A)	230 VAC	0.11 in H2O	27.4 Pa	-40 C	70 °C	70 °C	-40 °C	2000 RPM		53 CFM	1.48 mł/min	CE cUL TUV UL	0.725 lb	328.85 g	25 mm	2
Mechatronics Fan Group UF12B12-BTLR	Polybutylene Terephthalate (PBT)	50000 Hrs	110 mA	Aluminum	Tubeaxial	120 mm	120 mm	11 W	Ball	33 dB(A)	115 VAC	0.11 in H2O	27.4 Pa	-40 C	70 °C	70 °C	-40 °C	2000 RPM		53 CFM	1.48 mł/min	CE cUL TUV UL	0.725 lb	328.85 g	25 mm	2
Mechatronics Fan Group UF12B12-BTHR	Polybutylene Terephthalate (PBT)	50000 Hrs	120 mA	Aluminum	Tubeaxial	120 mm	120 mm	11 W	Ball	42 dB	115 VAC	0.24 in H2O	59.8 Pa	-40 C	70 °C	70 °C	-40 °C	2900 RPM		75 CFM	2.1 m³/min	CE cUL TUV UL	0.725 lb	328.85 g	25 mm	2
Mechatronics Fan Group UF12B12-BWHR-CC	Polybutylene Terephthalate (PBT)	50000 Hrs	150 mA	Aluminum	Tubeaxial	120 mm	120 mm	11 W	Ball	42 dB	115 VAC	0.24 in H2O	59.8 Pa	-40 C	70 °C	70 °C	-40 °C	2900 RPM	2 Wire Leads	75 CFM	2.1 m³/min	CE cUL TUV UL	0.725 lb	328.85 g	25 mm		Conformal Coating
