40.52.9 Series

Catalog

RELAY GEN PURPOSE DPDT 8A 110V

Part	Coil Resistance	Operating Temperature [Max]	Operating Temperature [Min]	Contact Form	Must Operate Voltage	Approval Agency	Switching Voltage [Max]	Coil Current	Termination Style	Mounting Type	Coil Voltage	Must Release Voltage	Release Time	Contact Material	Relay Type	Contact Rating (Current)	Load - Max Switching	Operate Time	Coil Type	Seal Rating
Finder Relays, Inc. 40.52.9.110.0001	18 kOhms	85 °C	-40 C	DPDT (2 Form C)	80.2 VDC	CCC CSA cURus EAC ENEC RINA VDE	400 VAC	6.2 mA	Plug In	Socketable	110 VDC	22 VDC	3 ms	Silver Nickel (AgNi)	General Purpose	8 A	3200 VA	7 ms	Non Latching
Finder Relays, Inc. 40.52.9.012.0300	220 Ohms	85 °C	-40 C	DPST-NO (2 Form A)	8.8 VDC	CCC CSA cURus EAC ENEC RINA VDE	400 VAC	55 mA	Plug In	Socketable	12 VDC	2.4 VDC	3 ms	Silver Nickel (AgNi)	General Purpose	8 A	3200 VA	7 ms	Non Latching	Sealed - Flux Protection
Finder Relays, Inc. 40.52.9.048.5000	3.5 kOhms	85 °C	-40 C	DPDT (2 Form C)	35 VDC	CCC CSA cURus EAC ENEC RINA VDE	400 VAC	14 mA	Plug In	Socketable	48 VDC	9.6 VDC	3 ms	Silver Nickel (AgNi)	General Purpose	8 A	3200 VA	7 ms	Non Latching	Sealed - Flux Protection
Finder Relays, Inc. 40.52.9.125.0000	23.5 kOhms	85 °C	-40 C	DPDT (2 Form C)	91.2 VDC	CCC CSA cURus EAC ENEC RINA VDE	400 VAC	5.3 mA	Plug In	Socketable	125 VDC	25 VDC	3 ms	Silver Nickel (AgNi)	General Purpose	8 A	3200 VA	7 ms	Non Latching	Sealed - Flux Protection
Finder Relays, Inc. 40.52.9.024.0300	900 Ohms	85 °C	-40 C	DPST-NO (2 Form A)	17.5 VDC	CCC CSA cURus EAC ENEC RINA VDE	400 VAC	27 mA	Plug In	Socketable	24 VDC	4.8 VDC	3 ms	Silver Nickel (AgNi)	General Purpose	8 A	3200 VA	7 ms	Non Latching	Sealed - Flux Protection
Finder Relays, Inc. 40.52.9.024.5001	900 Ohms	85 °C	-40 C	DPDT (2 Form C)	17.5 VDC	CCC CSA cURus EAC ENEC RINA VDE	400 VAC	27 mA	Plug In	Socketable	24 VDC	4.8 VDC	3 ms	Silver Nickel (AgNi)	General Purpose	8 A	3200 VA	7 ms	Non Latching
Finder Relays, Inc. 40.52.9.012.0001	220 Ohms	85 °C	-40 C	DPDT (2 Form C)	8.8 VDC	CCC CSA cURus EAC ENEC RINA VDE	400 VAC	55 mA	Plug In	Socketable	12 VDC	2.4 VDC	3 ms	Silver Nickel (AgNi)	General Purpose	8 A	3200 VA	7 ms	Non Latching
Finder Relays, Inc. 40.52.9.110.0000	18 kOhms	85 °C	-40 C	DPDT (2 Form C)	80.2 VDC	CCC CSA cURus EAC ENEC RINA VDE	400 VAC	6.2 mA	Plug In	Socketable	110 VDC	22 VDC	3 ms	Silver Nickel (AgNi)	General Purpose	8 A	3200 VA	7 ms	Non Latching	Sealed - Flux Protection
Finder Relays, Inc. 40.52.9.012.5000	220 Ohms	85 °C	-40 C	DPDT (2 Form C)	8.8 VDC	CCC CSA cURus EAC ENEC RINA VDE	400 VAC	55 mA	Plug In	Socketable	12 VDC	2.4 VDC	3 ms	Silver Nickel (AgNi)	General Purpose	8 A	3200 VA	7 ms	Non Latching	Sealed - Flux Protection
Finder Relays, Inc. 40.52.9.048.0000	3.5 kOhms	85 °C	-40 C	DPDT (2 Form C)	35 VDC	CCC CSA cURus EAC ENEC RINA VDE	400 VAC	14 mA	Plug In	Socketable	48 VDC	9.6 VDC	3 ms	Silver Nickel (AgNi)	General Purpose	8 A	3200 VA	7 ms	Non Latching	Sealed - Flux Protection
