173-E37 Series
Manufacturer: NorComp Inc.
Beta
⌘K
D SUB CONNECTOR, DB37, RECEPTACLE, 173-E M SERIES, 37 CONTACTS, DC, THROUGH HOLE
| Part | Color | Dielectric Material | Operating Temperature [Min] | Operating Temperature [Max] | Contact Material | Mounting Type | Shell Material, Finish | Current Rating (Amps) | Termination | Contact Finish | Connector Type | Contact Finish Thickness | Number of Positions | Flange Feature | Number of Rows [custom] | Backset Spacing | Backset Spacing | Contact Type | Connector Style | Shell Size, Connector Layout | Shell Size, Connector Layout | Material Flammability Rating | Shell Material, Finish [custom] | Shell Material, Finish [custom] | Features | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NorComp Inc. | White | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | Copper | Right Angle Through Hole | Nickel Plated Steel | 5 A | Solder | Gold | Receptacle Female Sockets | Flash | 37 | Housing/Shell (Unthreaded) | 2 | 7.2 mm | 0.283 in | Signal | D-Sub | 4 | DC C | UL94 V-0 | ||||
 NorComp Inc. | White | Polyamide (PA6T) Nylon 6T | -50 °C | 100 °C | Panel Mount Right Angle Through Hole | 5 A | Solder | Gold | Receptacle Female Sockets | Flash | 37 | Housing/Shell (Unthreaded) | 2 | 7.2 mm | 0.283 in | Signal | D-Sub | 4 | DC C | UL94 V-0 | Steel | Yellow Chromate Plated | ||||
 NorComp Inc. | White | Polyamide (PA6T) Nylon 6T | -50 °C | 100 °C | Brass | Panel Mount Right Angle Through Hole | Nickel Plated Steel | 5 A | Solder | Gold | Plug Male Pins | Flash | 37 | Housing/Shell (Unthreaded) | 2 | 7.2 mm | 0.283 in | Signal | D-Sub | 4 | DC C | UL94 V-0 | Grounding Indents | |||
 NorComp Inc. | White | Polybutylene Terephthalate (PBT) | -50 °C | 100 °C | Panel Mount Right Angle Through Hole | 5 A | Solder | Gold | Receptacle Female Sockets | Flash | 37 | Housing/Shell (Unthreaded) | 2 | 7.2 mm | 0.283 in | Signal | D-Sub | 4 | DC C | UL94 V-0 | ||||||
 NorComp Inc. | White | Polyamide (PA6T) Nylon 6T | -50 °C | 100 °C | Panel Mount Right Angle Through Hole | 5 A | Solder | Gold | Receptacle Female Sockets | Flash | 37 | Mating Side Standard Screws (4-40) | 2 | 7.2 mm | 0.283 in | Signal | D-Sub | 4 | DC C | UL94 V-0 | Steel | Yellow Chromate Plated | Mounting Brackets | |||
 NorComp Inc. | White | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | Copper | Right Angle Through Hole | Nickel Plated Steel | 5 A | Solder | Gold | Receptacle Female Sockets | Flash | 37 | Housing/Shell | 2 | 7.2 mm | 0.283 in | Signal | D-Sub | 4 | DC C | UL94 V-0 | Board Lock Mounting Brackets | 4-40 | ||
 NorComp Inc. | White | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | Copper | Right Angle Through Hole | Nickel Plated Steel | 5 A | Solder | Gold | Receptacle Female Sockets | Flash | 37 | 4-40 Mating Side Female Screwlock | 2 | 7.2 mm | 0.283 in | Signal | D-Sub | 4 | DC C | UL94 V-0 | Mounting Brackets | |||
 NorComp Inc. | White | Polyamide (PA6T) Nylon 6T | -50 °C | 100 °C | Brass | Panel Mount Right Angle Through Hole | Nickel Plated Steel | 5 A | Solder | Gold | Plug Male Pins | Flash | 37 | 4-40 Mating Side Female Screwlock | 2 | 7.2 mm | 0.283 in | Signal | D-Sub | 4 | DC C | UL94 V-0 | Grounding Indents Mounting Brackets | |||
 NorComp Inc. | White | Polyamide (PA6T) Nylon 6T | -50 °C | 100 °C | Brass | Panel Mount Right Angle Through Hole | 5 A | Solder | Gold | Plug Male Pins | Flash | 37 | Housing/Shell (Unthreaded) | 2 | 7.2 mm | 0.283 in | Signal | D-Sub | 4 | DC C | UL94 V-0 | Steel | Yellow Chromate Plated | |||
 NorComp Inc. | White | Polyamide (PA6T) Nylon 6T | -50 °C | 100 °C | Panel Mount Right Angle Through Hole | 5 A | Solder | Gold | Receptacle Female Sockets | Flash | 37 | 4-40 Mating Side Female Screwlock | 2 | 7.2 mm | 0.283 in | Signal | D-Sub | 4 | DC C | UL94 V-0 | Steel | Yellow Chromate Plated | Mounting Brackets |
