14_BMA-50 Series
Manufacturer: Huber+Suhner, Inc.
Beta
⌘K
14_BMA-50-2-33/133_NH
| Part | Mating Cycles | Body Finish | Body Material | Operating Temperature [Max] | Operating Temperature [Min] | Dielectric Material | Center Contact Plating | Connector Style | Impedance | Mounting Feature | Center Contact Material | Contact Termination | Fastening Type | Frequency - Max [Max] | Connector Type | Mounting Type | Number of Ports | Housing Color | Shield Termination | Cable Group | Cable Group |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Huber+Suhner, Inc. | 1000 | White Bronze | Brass | 125 °C | -40 C | Polytetrafluoroethylene (PTFE) | Gold | BMA | 50 Ohms | Bulkhead - Front Side Nut | Beryllium Copper | Crimp | Snap-On | 12.4 GHz | Plug Male Pin | Panel Mount | 1 | Silver | Solder | ||
 Huber+Suhner, Inc. | 1000 | Gold | Beryllium Copper | 125 °C | -65 ░C | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Gold | BMA | 50 Ohms | Bulkhead - Front Side Nut | Beryllium Copper | Crimp | Snap-On | 18 GHz | Plug Male Pin | Panel Mount | 1 | Gold | Solder | RG-405 (.086 Semi Rigid) | |
 Huber+Suhner, Inc. | 1000 | Stainless Steel | 125 °C | -65 ░C | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Gold | BMA | 50 Ohms | Bulkhead - Front Side Nut | Beryllium Copper Brass | Solder | Push-Pull | 18 GHz | Plug Male Pin | Panel Mount | 1 | Silver | Crimp | 188 316 RG-174 | ||
 Huber+Suhner, Inc. | 1000 | Gold | Beryllium Copper | 125 °C | -65 ░C | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Gold | BMA | 50 Ohms | Bulkhead - Front Side Nut | Beryllium Copper | Crimp | Snap-On | 18 GHz | Plug Male Pin | Panel Mount | 1 | Gold | Solder | RG-141 | |
 Huber+Suhner, Inc. | 1000 | White Bronze | Brass | 125 °C | -40 C | Polytetrafluoroethylene (PTFE) | Gold | BMA | 50 Ohms | Bulkhead - Front Side Nut | Beryllium Copper | Crimp | Snap-On | 12.4 GHz | Plug Male Pin | Panel Mount | 1 | Silver | Solder | RG-141 | |
 Huber+Suhner, Inc. | 1000 | White Bronze | Brass | 125 °C | -40 C | Polytetrafluoroethylene (PTFE) | Gold | BMA | 50 Ohms | Bulkhead - Front Side Nut | Beryllium Copper Brass | Solder | Snap-On | 12.4 GHz | Plug Male Pin | Panel Mount | 1 | Silver | Crimp | RG-142 | 400 |
 Huber+Suhner, Inc. | 1000 | Stainless Steel | 125 °C | -65 ░C | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Gold | BMA | 50 Ohms | Bulkhead - Front Side Nut | Beryllium Copper Brass | Solder | Snap-On | 18 GHz | Plug Male Pin | Panel Mount | 1 | Silver | Crimp | 223 RG-142 |
