11_BNC-50 Series
Manufacturer: Huber+Suhner, Inc.
Beta
⌘K
11_BNC-50-4-53/133_NE
| Part | Contact Termination | Mounting Type | Connector Style | Fastening Type | Frequency - Max [Max] | Number of Ports | Connector Type | Housing Color | Shield Termination | Center Contact Material | Impedance | Voltage Rating | Body Material | Operating Temperature [Min] | Operating Temperature [Max] | Mating Cycles | Body Finish | Center Contact Plating | Dielectric Material | Cable Group | Cable Group |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Huber+Suhner, Inc. | Solder | Free Hanging (In-Line) | BNC | Bayonet Lock | 4 GHz | 1 | Plug Male Pin | Silver | Crimp | Beryllium Copper | 50 Ohms | ||||||||||
 Huber+Suhner, Inc. | Solder | Free Hanging (In-Line) | BNC | Bayonet Lock | 4 GHz | 1 | Plug Male Pin | Silver | Clamp | Brass | 50 Ohms | 500 V | Brass | -65 ░C | 165 °C | 500 | White Bronze | Gold | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | 142 223 400 | RG-58 |
 Huber+Suhner, Inc. | Crimp | Free Hanging (In-Line) | BNC | Bayonet Lock | 4 GHz | 1 | Plug Male Pin | Silver | Crimp | Brass | 50 Ohms | 500 V | Brass | -65 ░C | 165 °C | 500 | White Bronze | Gold | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | RG-59 | |
 Huber+Suhner, Inc. | Solder | Free Hanging (In-Line) | BNC | Bayonet Lock | 4 GHz | 1 | Plug Male Pin | Silver | Clamp | Brass | 50 Ohms | 500 V | Brass | -65 ░C | 165 °C | 500 | White Bronze | Gold | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | RG-213 | |
 Huber+Suhner, Inc. | Crimp | Free Hanging (In-Line) | BNC | Bayonet Lock | 4 GHz | 1 | Plug Male Pin | Silver | Crimp | Brass | 50 Ohms | 500 V | Brass | -65 ░C | 165 °C | 500 | White Bronze | Gold | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | ||
 Huber+Suhner, Inc. | Crimp | Free Hanging (In-Line) | BNC | Bayonet Lock | 4 GHz | 1 | Plug Male Pin | Silver | Crimp | Brass | 50 Ohms | 500 V | Brass | -65 ░C | 165 °C | 500 | White Bronze | Gold | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | RG-214 | |
Huber+Suhner, Inc. | Crimp | Free Hanging (In-Line) | BNC | Bayonet Lock | 4 GHz | 1 | Plug Male Pin | Silver | Crimp | Brass Bronze | 50 Ohms | 500 V | Brass | -65 ░C | 165 °C | 500 | White Bronze | Gold | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | RD-316 | |
 Huber+Suhner, Inc. | |||||||||||||||||||||
 Huber+Suhner, Inc. | Crimp | Free Hanging (In-Line) | BNC | Bayonet Lock | 4 GHz | 1 | Plug Male Pin | Silver | Crimp | Brass Bronze | 50 Ohms | 500 V | Brass | -65 ░C | 165 °C | 500 | White Bronze | Gold | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | 188 316 RG-174 | |
Huber+Suhner, Inc. | Crimp | Free Hanging (In-Line) | BNC | Bayonet Lock | 4 GHz | 1 | Plug Male Pin | Silver | Crimp | Beryllium Copper Brass | 50 Ohms | 500 V | Brass | -65 ░C | 165 °C | 500 | White Bronze | Gold | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | RD-316 |
