lb-snap-in Series
Manufacturer: NKK Switches
Beta
⌘K
SWITCH: PUSH-BUTTON; POS: 2; DPDT; 3A/250VAC; 3A/30VDC; ON-ON; 200MΩ
| Part | Actuator Marking | Type | Voltage Rating - AC | Current Rating (Amps) | Termination Style | Circuit | Actuator Type | Panel Cutout Dimensions [x] | Panel Cutout Dimensions [y] | Switch Function | Operating Temperature [Min] | Operating Temperature [Max] | Voltage Rating - DC | Mounting Type | Panel Cutout Dimensions [diameter] | Mechanical Life | Electrical Life |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NKK Switches | No Marking | Standard | 125 V | 3 A | Solder Quick Connect - 0.110" (2.8mm) | DPDT | Plunger for Cap | 16.2 mm | 16.2 mm | On-On | -25 °C | 70 °C | 30 V | Panel Mount Snap-In | |||
 NKK Switches | No Marking | Standard | 125 V | 3 A | Solder Quick Connect - 0.110" (2.8mm) | DPDT | Plunger for Cap | On-Mom | -25 °C | 70 °C | 30 V | Panel Mount Snap-In | 22 mm | ||||
 NKK Switches | No Marking | Standard | 125 V | 3 A | Solder Quick Connect - 0.110" (2.8mm) | SPDT | Plunger for Cap | 22.4 mm | 16.2 mm | On-Mom | -25 °C | 70 °C | 30 V | Panel Mount Snap-In | |||
 NKK Switches | No Marking | Standard | 125 V | 3 A | Solder Quick Connect - 0.110" (2.8mm) | SPDT | Plunger for Cap | 22.4 mm | 16.2 mm | On-Mom | -25 °C | 70 °C | 30 V | Panel Mount Snap-In | 1000000 Cycles | 100000 Cycles |
