HT46C Series
Manufacturer: Leuze
Beta
⌘K
DIFFUSE BACKGROUND SUPPRESSION
| Part | Ingress Protection | Voltage - Supply (Minimum) | Voltage - Supply (Maximum) | Sensing Method | Adjustment Type | Light Source | Output Configuration | Sensing Distance Minimum | Sensing Distance Maximum | Operating Temperature (Max) | Operating Temperature (Min) | Connection Method | Response Time | Light Source Wavelength (Infrared) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Leuze | IEC 60947-5-2 IEC 60947-5-2 IP67 IEC 60947-5-2 IP69K IP67 IP69K | 10 VDC | 30 VDC | Background Suppression Diffuse | Adjustable | Red LED | Light-ON PNP - Dark-ON | 0.197 " | 118.11 " | 60 °C | -40 °C | Connector M12 | 2 ms | |
Leuze | IEC 60947-5-2 IEC 60947-5-2 IP67 IEC 60947-5-2 IP69K IP67 IP69K | 10 VDC | 30 VDC | Background Suppression Diffuse | Adjustable Potentiometer | Infrared | Light-ON PNP - Dark-ON | 0.197 " | 118.11 " | 60 °C | -40 °C | Connector M12 | 2 ms | 860 nm |
