K86X-CD Series
Manufacturer: Kycon, Inc.
Beta
⌘K
CONN D-SUB HD RCPT 62P VERT SLDR
| Part | Dielectric Material | Color | Voltage Rating | Operating Temperature [Min] | Operating Temperature [Max] | Contact Form | Contact Material | Flange Feature | Material Flammability Rating | Mounting Type | Contact Finish Thickness | Contact Finish Thickness | Number of Positions | Contact Type | Number of Rows [custom] | Shell Size, Connector Layout | Shell Size, Connector Layout | Termination | Contact Finish | Shell Material, Finish | Connector Type | Connector Style | Current Rating (Amps) | Features | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Kycon, Inc. | Polybutylene Terephthalate (PBT) Glass Filled | Black | 30 VAC | -55 C | 75 ░C | Stamped | Brass | Housing/Shell (Unthreaded) | UL94 V-0 | Through Hole | 30 Áin | 0.76 Ám | 62 | Signal | 3 | C DC | 4 | Solder | Gold | Nickel Plated Steel | Receptacle Female Sockets | D-Sub High Density | 1.5 A | ||
Kycon, Inc. | Polybutylene Terephthalate (PBT) Glass Filled | Black | 30 VAC | -55 C | 75 ░C | Stamped | Brass | Board Side (4-40) Mating Side Female Screwlock (4-40) | UL94 V-0 | Through Hole | 30 Áin | 0.76 Ám | 62 | Signal | 3 | C DC | 4 | Solder | Gold | Nickel Plated Steel | Receptacle Female Sockets | D-Sub High Density | 1.5 A | ||
 Kycon, Inc. | Polybutylene Terephthalate (PBT) Glass Filled | Black | 30 VAC | -55 C | 105 ░C | Stamped | Brass | Board Side (4-40) | UL94 V-0 | Through Hole | 62 | Signal | 3 | C DC | 4 | Solder | Gold | Nickel Plated Steel | Plug Male Pins | D-Sub High Density | 1.5 A | Board Lock Grounding Indents | Flash |
