PREC019 Series

Manufacturer: Sullins Connector Solutions

Catalog

CONN HEADER R/A 38POS 2.54MM

Part	Contact Material	Contact Finish - Post	Contact Length - Mating	Contact Length - Mating	Mounting Type	Insulation Material	Number of Positions	Shrouding	Pitch - Mating	Pitch - Mating	Material Flammability Rating	Insulation Color	Number of Rows [custom]	Contact Length - Post	Contact Length - Post	Operating Temperature [Min]	Operating Temperature [Max]	Connector Type	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Fastening Type	Termination	Number of Positions Loaded	Style	Insulation Height	Insulation Height	Current Rating (Amps)	Contact Shape	Contact Type	Number of Rows	Overall Contact Length	Overall Contact Length	Overall Contact Length [x]	Overall Contact Length [x]
Sullins Connector Solutions PREC019DBAN-M71RC	Brass	Tin	0.23 in	5.84 mm	Right Angle Through Hole	Polybutylene Terephthalate (PBT)	38	Unshrouded	0.1 "	2.54 mm	UL94 V-0	Black	2	3.05 mm	0.12 in	-40 C	105 ░C	Header Breakaway	0.1 in	2.54 mm	Push-Pull	Solder	All	Board to Board Cable	0.197 "	5 mm	3 A	Square	Male Pin
Sullins Connector Solutions PREC019SAAN-RC	Brass	Tin	0.23 in	5.84 mm	Through Hole	Polybutylene Terephthalate (PBT)	19	Unshrouded	0.1 "	2.54 mm	UL94 V-0	Black		3.05 mm	0.12 in	-40 C	105 ░C	Header Breakaway			Push-Pull	Solder	All	Board to Board Cable	0.098 "	2.5 mm	3 A	Square	Male Pin	1	0.448 in	11.39 mm
Sullins Connector Solutions PREC019SFAN-RC	Brass	Tin	0.318 in	8.08 mm	Through Hole	Polybutylene Terephthalate (PBT)	19	Unshrouded	0.1 "	2.54 mm	UL94 V-0	Black		3.05 mm	0.12 in	-40 C	105 ░C	Header Breakaway			Push-Pull	Solder	All	Board to Board Cable	0.098 "	2.5 mm	3 A	Square	Male Pin	1			13.63 mm	0.537 in
Sullins Connector Solutions PREC019SACN-RC	Brass	Tin	0.23 in	5.84 mm	Through Hole	Polybutylene Terephthalate (PBT)	19	Unshrouded	0.1 "	2.54 mm	UL94 V-0	Black		8.13 mm	0.32 in	-40 C	105 ░C	Header Breakaway			Push-Pull	Solder	All	Board to Board Cable	0.098 "	2.5 mm	3 A	Square	Male Pin	1			16.47 mm	0.648 in
Sullins Connector Solutions PREC019SABN-RC	Brass	Tin	0.23 in	5.84 mm	Through Hole	Polybutylene Terephthalate (PBT)	19	Unshrouded	0.1 "	2.54 mm	UL94 V-0	Black		5.84 mm	0.23 "	-40 C	105 ░C	Header Breakaway			Push-Pull	Solder	All	Board to Board Cable	0.098 "	2.5 mm	3 A	Square	Male Pin	1	0.558 in	14.18 mm
Sullins Connector Solutions PREC019DAAN-RC	Brass	Tin	0.23 in	5.84 mm	Through Hole	Polybutylene Terephthalate (PBT)	38	Unshrouded	0.1 "	2.54 mm	UL94 V-0	Black	2	3.05 mm	0.12 in	-40 C	105 ░C	Header Breakaway	0.1 in	2.54 mm	Push-Pull	Solder	All	Board to Board Cable	0.098 "	2.5 mm	3 A	Square	Male Pin		0.448 in	11.39 mm
Sullins Connector Solutions PREC019DFAN-RC	Brass	Tin	0.318 in	8.08 mm	Through Hole	Polybutylene Terephthalate (PBT)	38	Unshrouded	0.1 "	2.54 mm	UL94 V-0	Black	2	3.05 mm	0.12 in	-40 C	105 ░C	Header Breakaway	0.1 in	2.54 mm	Push-Pull	Solder	All	Board to Board Cable	0.098 "	2.5 mm	3 A	Square	Male Pin				13.63 mm	0.537 in
Sullins Connector Solutions PREC019SBBN-M71RC	Brass	Tin	0.23 in	5.84 mm	Right Angle Through Hole	Polybutylene Terephthalate (PBT)	19	Unshrouded	0.1 "	2.54 mm	UL94 V-0	Black		5.58 mm	0.22 in	-40 C	105 ░C	Header Breakaway			Push-Pull	Solder	All	Board to Board Cable	0.098 "	2.5 mm	3 A	Square	Male Pin	1
