DRV8316C-Q1 Series
Automotive 40-V max 8-A peak three-phase motor driver with integrated current sensing
Manufacturer: Texas Instruments
Catalog
Automotive 40-V max 8-A peak three-phase motor driver with integrated current sensing
Beta
⌘K
Automotive 40-V max 8-A peak three-phase motor driver with integrated current sensing
Automotive 40-V max 8-A peak three-phase motor driver with integrated current sensing
Automotive 40-V max 8-A peak three-phase motor driver with integrated current sensing
| Part | Voltage - Supply [Min] | Voltage - Supply [Max] | Function | Supplier Device Package | Motor Type - Stepper | Current - Output | Technology | Grade | Voltage - Load [Max] | Voltage - Load [Min] | Motor Type - AC, DC | Interface | Package / Case | Output Configuration | Mounting Type | Operating Temperature [Min] | Operating Temperature [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Texas Instruments | 4.5 V | 35 V | Driver - Fully Integrated Control and Power Stage | 40-VQFN | Multiphase | 8 A | NMOS | Automotive | 35 V | 4.5 V | Brushless DC (BLDC) | PWM | 40-VFQFN Exposed Pad | Half Bridge (3) | Surface Mount | -40 °C | 125 °C |
 Texas Instruments | 4.5 V | 35 V | Driver - Fully Integrated Control and Power Stage | 40-VQFN | Multiphase | 8 A | NMOS | Automotive | 35 V | 4.5 V | Brushless DC (BLDC) | PWM SPI | 40-VFQFN Exposed Pad | Half Bridge (3) | Surface Mount | -40 °C | 125 °C |
